Azbil GTX35R-BAAXXX1 Remote Seal Differential Pressure Transmitter Unit

Feature & Principle

This remote sealed differential pressure transmitter calculates liquid level or differential pressure by detecting pressure difference between two remote seal diaphragms. Filled capillary transfers process pressure to the sensor element, avoids direct contact between sensor and corrosive, sticky or high-temperature medium. It supports HART digital communication, on-site zero adjustment, built-in self-diagnosis, SIL2 safety certification.

Specifications

Model: GTX35R-BAAXXX1 Brand: Azbil Series: GTX35R Measuring span: 2.5 ~ 100kPa Output: 4-20mA + HART Diaphragm fill fluid: Silicone oil Accuracy: ±0.2% Safety: SIL2 Protection: IP67 Certification: IEC61508, CE

Components & Diagnostics

Transmitter electronic head, pressure sensing module, capillary tube, remote seal flange diaphragm, terminal block and display module. Common faults include capillary oil leakage, diaphragm scaling, signal drift, HART communication failure and power supply abnormality.

Product Brief

GTX35R-BAAXXX1 transmitter, Azbil instrument spare widely used for chemical storage tank, oil tank, high viscosity medium and high temperature process level and differential pressure continuous measurement.
