B&R 0AC808.9 Industrial Ethernet Hub

Technical Specifications

Model:0AC808.9

Brand:B&R（贝加莱）

Product Type:Layer2 Industrial Ethernet Hub

Applicable System:B&R POWERLINK bus system, standard industrial Ethernet automation network

Port quantity:8×shielded RJ45 ports

Transmission rate:10/100Mbps, auto‑negotiation, AUTO‑MDIX

Power supply:18‑30VDC, max 150mA, max power consumption 3W

Isolation:Each port electrical isolation, isolation between port and power supply

Installation:DIN‑rail mounting, supports horizontal and vertical installation

Degree of protection:IP20

Dimension:115mm86mm43mm

Weight:0.49kg

Status indicator:Per‑channel link/collision LED, network activity LED, power supply status LED

Working temperature:‑25℃ ~ +60℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function:Ethernet signal forwarding, network status diagnosis, anti‑surge protection, supports POWERLINK real‑time bus network topology expansion

Remark:4‑pin power terminal block needs to be purchased separately

Product Brief

0AC808.9 is B&R discontinued 8‑port layer 2 industrial Ethernet hub, widely used for POWERLINK real‑time bus and ordinary industrial Ethernet network topology expansion.

It adopts shielded RJ45 interface, supports auto‑negotiation and AUTO‑MDIX function, no need to distinguish straight‑through or crossover cable, simplifies field wiring work. Each channel is equipped with independent LED indicator, convenient for technicians to quickly judge link status, network collision and communication fault.

The module supports DIN‑rail installation, adapts to cabinet horizontal and vertical installation modes, with wide‑range DC power supply and perfect electrical isolation performance, can restrain ground loop interference in industrial site.

This is EOL discontinued spare part, mainly used for maintenance and renovation of old‑generation B&R automation control system. Please confirm network topology and matching terminal block before purchasing. Strict ESD protection should be followed during installation.
