B&R 4B1270.00‑490 Panelware Compact Operator Panel

Technical Specifications

Model:4B1270.00‑490

Brand:B&R

Product Type:Compact Character‑Based Operator Panel

Applicable System:B&R System2005 PCC controller, packaging, textile and plastic processing machinery

Display:4×20 character LCD, LED backlight, brightness 200 cd/m²

Interface:1×isolated CAN bus, 9‑pin male DSUB connector, max baud rate 500 kbit/s

Key array:12 function keys with yellow LED indicator, slide‑in key label support

Power supply:18‑30VDC, typical 2.8W, max 3.3W power consumption

Installation:Panel cut‑out mounting for cabinet front‑panel

Degree of protection:IP20 rear side, front‑panel IP54

Weight:0.42kg

Working temperature:0℃ ~ +50℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function:Character‑based data display, parameter modification, machine status monitoring, alarm message output, isolated CAN‑bus communication, key‑input processing, controlled by PLC escape sequences without local image memory

Product Brief

4B1270.00‑490 is B&R Panelware series compact character‑type operator panel, communicating with B&R System2005 controller via galvanic isolated CAN bus.

It adopts 4‑row 20‑character LCD with LED backlight, shows process values, set‑points and alarm texts. 12 LED‑backlit function keys support user‑defined slide‑in labels for convenient on‑site operation. This panel has no local image memory, all display actions are driven by PLC escape‑sequence commands.

Isolated CAN interface restrains ground‑loop interference on industrial cabinet sites, maximum communication distance reaches 1000 m at low baud rate. Front‑panel IP54 rating provides basic dust and splash resistance for cabinet‑mount installation.

This is EOL discontinued spare part, widely used for legacy packaging and textile equipment maintenance. Please confirm CAN‑bus topology and controller compatibility before purchase. Strict ESD protection shall be followed during installation.
