B&R 4B1500.00‑590 P150 Intelligent Operator Panel

Technical Specifications

Model:4B1500.00‑590

Brand:B&R

Product Type:P150 Panelware Intelligent Operator HMI Panel

Applicable System:B&R System2005 PCC control system, packaging, textile and plastic processing machinery

Memory:256KB SRAM,256KB FlashPROM non‑volatile memory, supports local parameter storage

Display:Character‑based LCD with LED backlight

Interface:1×galvanic isolated CAN‑bus DSUB‑9 connector

Key array:Numeric keys and multi‑function keys with LED indicator, supports slide‑in key label

Power supply:18‑30VDC wide‑range DC input

Installation:Cabinet front‑panel cut‑out mounting

Degree of protection:Front IP54, rear side IP20

Dimension:195mm195mm60mm

Weight:1.00kg

Status indicator:Communication LED, key‑function LED indicators for operating status diagnosis

Working temperature:0℃ ~ +50℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function:Local parameter persistent storage, process data display, set‑point modification, alarm message processing, isolated CAN‑bus cyclic data exchange with System2005 PCC controller, independent local data buffer reducing CPU communication load

Product Brief

4B1500.00‑590 is B&R EOL discontinued P150 series intelligent Panelware operator panel for System2005 control system. Different from basic Panelware units, this panel is equipped with on‑board 256KB SRAM and 256KB FlashPROM memory, capable of storing parameters and partial project data locally, easing host CPU communication burden.

It adopts character‑type LCD display with LED backlight, complete numeric and function key array with LED feedback, convenient for operators to modify production parameters and read equipment alarm information. Galvanic isolated CAN‑bus interface improves anti‑interference ability for industrial cabinet environment.

Front‑side IP54 protection rating adapts to standard cabinet installation scenarios, widely deployed on legacy packaging, textile and plastic machinery.

This is legacy EOL spare part for old‑system renovation. Please confirm CAN‑bus baud rate and System2005 controller compatibility before purchase. Strict ESD anti‑static protection shall be followed during installation.
