B&R 4E0050.01‑590 Panelware Dummy Keypad Module

Technical Specifications

Model:4E0050.01‑590

Brand:B&R

Product Type:Panelware Dummy Filler Keypad Module

Applicable System:B&R Panelware HMI system, covers vacant 96×96mm keypad cut‑out positions, cooperates with 4C‑series panel controller

Installation:Cabinet front‑panel cut‑out mounting, 96 mm × 96 mm standard Panelware cut‑out

Dimension:96mm96mm35mm

Weight:0.10kg

Degree of protection:Front IP65, rear IP20

Working temperature:0℃ ~ +50℃

Storage temperature:‑20℃ ~ +60℃

Relative humidity:5‑95% non‑condensing

Vibration / Shock:Compliant with IEC 60068‑2‑6, IEC 60068‑2‑27

Built‑in function:Pure mechanical blank cover, seals unused keypad cut‑out openings, prevents dust and metal debris entering cabinet interior, maintains complete front‑panel IP65 shielding performance, no electrical circuit and keypad function

Product Brief

4E0050.01‑590 is B&R EOL discontinued mechanical dummy filler module for Panelware HMI system. It occupies standard 96×96 mm keypad cut‑out position on cabinet front‑panel when no physical keypad unit is installed.

This filler unit has no electronic components, no key‑input function and requires zero software configuration. It closes vacant panel openings to avoid dust, splash and metal debris falling into cabinet interior, preserving IP65 environmental protection rating for HMI operator panel assembly.

It is widely used for cabinet reconstruction of legacy System2005 packaging, textile and plastic machinery.

This is legacy EOL spare part. Please confirm Panelware panel cut‑out dimension before purchase. Strict ESD anti‑static protection shall be followed during installation.
