B&R 4E0021.01‑090 Panelware Numeric Keypad Module

Technical Specifications

Model:4E0021.01‑090

Brand:B&R

Product Type:Panelware Numeric Keypad Module

Applicable System:B&R Panelware HMI system, cooperates with 4C‑series panel controller for System2005 PCC, packaging, textile and plastic machinery

Key quantity:12 numeric keys, 4 function keys with integrated yellow LED indicator

Label support:User‑insertable custom key legend sheets

Connection:Special dedicated internal connecting cable, no standard field‑bus connector

Power supply:Power supplied by matched 4C‑series panel controller, 24VDC

Installation:Cabinet front‑panel cut‑out mounting

Dimension:96mm96mm35mm

Weight:0.10kg

Degree of protection:Front IP65, rear IP20

Certification:CE, cULus

Working temperature:0℃ ~ +50℃

Storage temperature:‑20℃ ~ +60℃

Relative humidity:5‑95% non‑condensing

Vibration / Shock:Compliant with IEC 60068‑2‑6, IEC 60068‑2‑27

Built‑in function:Numeric value input, parameter modification, LED status indication, transmits key trigger signal to backend 4C‑series panel controller via dedicated cable, provides numeric operating interface for Panelware HMI system

Product Brief

4E0021.01‑090 is B&R EOL discontinued Panelware numeric keypad module. It cannot operate standalone and must be connected to 4C‑series Panelware backend controller by special dedicated internal cable.

It provides 12‑channel numeric input keys for set‑point entry and parameter modification, four keys are equipped with yellow LED for status feedback. User‑replaceable key legend sheets allow flexible function definition for different machinery applications. Front‑side IP65 rating delivers dust and splash resistance for cabinet‑mount installation.

All key‑signal processing is executed by backend panel controller. Widely deployed on legacy packaging, textile and plastic forming equipment.

This is legacy EOL spare part for old‑equipment maintenance and renovation. Please confirm 4C‑series controller compatibility and dedicated cable availability before purchase. Strict ESD anti‑static protection shall be followed during installation.
