B&R 5AP920.1505‑K16 Automation Panel

Technical Specifications

Model:5AP920.1505‑K16

Brand:B&R

Product Type:AP920 series cabinet‑mount industrial operator panel with PPC300 expansion slot

Applicable System:B&R Automation system, packaging machinery, beverage production equipment and general industrial automation projects

Display:15‑inch color TFT‑LCD,1024×768 XGA resolution,16.7 million colors,350 cd/m² typical brightness,CCFL backlight

Touch type:Analog resistive touch screen,serial Elo touch controller,81% light transmittance

Memory:256 MB SDRAM onboard,1×CompactFlash Type‑I slot for program and data storage

Communication interfaces:2×10/100Mbps Ethernet port,1×RS232 serial port,multiple USB2.0 Type‑A host ports

Expansion resource:PPC300 internal expansion slot,supports matching panel PC host module installation

Power supply:24VDC SELV power input,max 3.2A power consumption

Installation:Cabinet front cut‑out mounting,equipped with front‑face sealing gasket

Dimension:435mm330mm54mm

Weight:5.78kg

Degree of protection:Front‑side IP65,rear‑side IP20(valid under correct installation and intact gasket)

Certification:CE,cULus certification

Working temperature:0℃ ~ +55℃

Storage temperature:‑20℃ ~ +70℃

Relative humidity:5‑95% non‑condensing

Built‑in function:Real‑time production data display,alarm and event message output,recipe parameter setting and modification,multi‑channel network communication,realize man‑machine interaction with B&R automation controller via expansion slot.

Product Brief

5AP920.1505‑K16 belongs to B&R AP920 Automation Panel series cabinet‑mount operation panel, it is equipped with PPC300 expansion slot, which can be installed with matching host module to complete the whole HMI control function.

15‑inch XGA color TFT screen clearly presents process parameters,production recipes and equipment fault information. Analog resistive touch is suitable for on‑site workshop environment with dust and oil pollution,stable and durable for long‑time industrial operation. Dual Ethernet ports support network redundancy and multi‑device interconnection,CompactFlash slot facilitates local program backup and data recording.

Aluminum alloy front frame with sealing gasket realizes front‑panel IP65 protection,adapt to various cabinet‑mount installation conditions. This is discontinued legacy spare part,widely used for maintenance and renovation of old packaging and beverage production lines. Please confirm the compatibility of PPC300 host module,cabinet cut‑out dimension and system software before purchase. Strict ESD anti‑static measures shall be taken during installation.
