B&R 7EX484.50‑1 POWERLINK Bus Controller Module

Technical Specifications

Model:7EX484.50‑1

Brand:B&R

Product Type:Series2003 high‑performance POWERLINK real‑time Ethernet bus controller module

Applicable System:B&R Automation Studio,Series2003 I/O system,motion‑control equipment,packaging machinery,printing lines,real‑time distributed I/O stations

Communication Interfaces:4×shielded RJ45 POWERLINK ports,built‑in internal hub,100 Mbps IEEE802.3,each port galvanic isolated;max segment cable length 100m;support line,star and ring network topology

Hardware Setting:Rotary dial switch for local POWERLINK station address setting

Diagnostic Indication:Multi‑color LED for module RUN status,bus error,TX/RX port activity diagnosis

Power supply:18‑30 VDC nominal 24VDC SELV;max power consumption 20W;power supplied via Series2003 backplane base unit

Terminal:Power terminal block 0TB704.9 / 0TB704.91 ordered separately

Installation:Plug‑in onto Series2003 backplane base holder

Dimension:127mm76mm102mm

Weight:0.48kg

Degree of protection:IP20

Certification:CE,cULus,UKCA certification

Working temperature:‑20℃ ~ +60℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5‑95% non‑condensing,pollution degree 2

Built‑in function:Real‑time Ethernet gateway converts POWERLINK field‑bus traffic into Series2003 local backplane I/O signals. Integrated hub simplifies field wiring without extra external switch. Galvanic‑isolated ports restrain ground‑loop interference for motion‑critical automation. Rotary dial realizes fast station‑number setting on site. LED indicators quickly locate bus communication fault. It allows Series2003 screw‑in I/O modules to work as remote POWERLINK controlled nodes.

Product Brief

7EX484.50‑1 is high‑end POWERLINK bus gateway of B&R Series2003 control system. Different from single‑port 7EX481.50‑1,it integrates four RJ45 ports with internal hub,supports flexible network topology for multi‑axis motion‑control projects.

Each POWERLINK port adopts galvanic isolation design,improves system stability under heavy‑interference industrial workshop. Rotary dial switch can set station number without software configuration,convenient for field commissioning and replacement. Multi‑color LED monitors module running status,bus error and port sending‑receiving activity for fast troubleshooting.

This is legacy EOL discontinued spare part,widely used for maintenance and hardware replacement of old‑generation motion‑oriented Series2003 distributed automation lines. Before purchase,please confirm Series2003 base holder compatibility and POWERLINK master station matching. ESD anti‑static protection shall be performed during installation,hot‑swap under powered‑on state is prohibited. Power terminal block must be purchased separately.
