B&R ECR165‑0 Combined Digital I/O Module

Technical Specifications

Model:ECR165‑0 (ECR165)

Brand:B&R

Product Type:MULTI‑CONTROL rack series combined digital input output module

Applicable System:B&R Midi‑Multi‑Control rack system,applied for early‑generation packaging machinery,automated process equipment for sensor signal acquisition and solenoid valve actuator drive

Input Voltage:24VDC

Output Rating:24VDC,0.5A per channel

Channel Quantity:16 digital inputs,16 digital outputs

Isolation:optocoupler galvanic isolation between field side and bus side

Protection:output channel short‑circuit protection

Indicator:channel‑by‑channel LED status display

Power Consumption:2.0W

Installation:Install in MULTI‑CONTROL rack slot

Degree of protection:IP20

Certification:CE,UL

Working temperature:0℃ ~ +55℃

Storage temperature:‑25℃ ~ +70℃

Relative humidity:5‑85% non‑condensing,pollution degree 2

Built‑in function:Rack‑mounted combined I/O module integrates digital input and output functions. It collects field proximity switch and contact signals,and outputs switch signals to drive relays,solenoid valves and indicator lamps. Optocoupler isolation enhances anti‑interference ability for industrial site environment. Short‑circuit protection prevents damage caused by field wiring faults,LED indicators support fast on‑site fault diagnosis

Product Brief

ECR165‑0 belongs to B&R MULTI‑CONTROL old‑generation I/O family,it is discontinued legacy spare part integrating input and output channels. Compact rack‑mount design saves hardware slot resources. Widely used for original B&R old‑equipment maintenance and renovation. Before purchase,please confirm rack hardware version and slot compatibility requirement. ESD anti‑static protection shall be followed during installation
