B&R X20PS9500 Compact CPU Power Supply Module

Technical Specifications

Model:X20PS9500

Brand:B&R

CPU/X2X‑Link input voltage:24VDC(-15% / +20%)

Max input current:0.7A

Nominal output power:7W for CPU and X2X‑Link

I/O power input:24VDC(-15% / +20%),max 10A external slow‑blow fuse required

Interfaces:CAN bus up to 1Mbit/s,RS232 up to 115.2kbit/s

Protection:Integrated non‑replaceable fuse,reverse‑polarity protection for CPU side,short‑circuit proof

Operation mode:Supports parallel connection and redundant power supply

Power consumption:1.42W

Protection class:IP20

Horizontal operating temperature:‑25℃ ~ +60℃

Vertical operating temperature:‑25℃ ~ +50℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function

X20PS9500 power supply module supplies compact / fieldbus CPU,X2X‑Link bus and station internal I/O. Integrated CAN and RS232 interfaces support debugging and data communication. Parallel redundant power mode improves system reliability,built‑in protection enhances anti‑interference performance,support local X20 station and distributed X2X‑Link remote stations deployment.

Product Brief

X20PS9500 belongs to B&R X20 I/O system family,coated variant X20cPS9500 is available for harsh environment. Fits X20BB22/X20BB27/X20BB32/X20BB37 CPU base,terminal block sold separately. External slow‑blow fuse must be configured. Widely used for original B&R automation equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation
