Bently Nevada 13188-02 Gateway Module

Feature & Principle

It is a dedicated communication gateway accessory for Bently Nevada 3500 online condition monitoring system. It reads vibration, speed and temperature data from each monitoring module in the rack through backplane bus, converts internal proprietary protocol into Modbus TCP / Ethernet signal, and uploads data to external DCS, SCADA and HMI. It supports remote parameter viewing and alarm transmission, provides isolated network interface to avoid interference, and is widely used for turbine, compressor and pump condition monitoring networking.

Specifications

Model: 13188-02 Brand: Bently Nevada Applicable rack: 3500 series machinery monitoring system Communication protocol: Modbus TCP, Ethernet Network interface: 10BASE-T Mounting: Single slot inside 3500 rack Power supply: Powered by rack backplane Operating temperature: -20℃ ~ +65℃ Lifecycle: Discontinued legacy spare Application: Power plant, refinery, chemical rotating equipment monitoring cabinet Certification: CE, ATEX optional

Components & Diagnostics

Main communication PCB, Ethernet transceiver circuit, backplane gold-plated connector, status LED indicators, metal shielding housing. Common faults: network communication drop, module offline, data no refresh, backplane contact failure.

Product Brief

13188-02 communication gateway module, Bently Nevada 3500 monitoring rack spare widely used for rotating machinery online monitoring cabinet overhaul and replacement.
