Bently Nevada 3500/60 Temperature Monitor Module

Technical Specifications

Model: 3500/60

Brand: Bently Nevada

Product Type: 6‑channel temperature monitor module

Spare Part No: 133819‑01,163179‑01

Channel Layout: 6 independent temperature input channels,mixed RTD / TC input supported

Supported Transducer: 3‑wire / 4‑wire platinum RTD,multiple types of thermocouples

Input Impedance: ≥10 MΩ per lead

Measurement Function: absolute temperature,differential temperature calculation

Alarm Function: user‑programmable alert and danger alarm thresholds

Power Consumption: 7.0 W,supplied by 3500 rack backplane

Status Indicator: OK LED,TX/RX communication LED,BYPASS LED

I/O Version Option: non‑isolated RTD/TC version; TC isolated version with 250 Vdc channel‑to‑channel isolation

System Compatibility: Bently Nevada 3500 machinery protection rack

Remark: No recorder analog output; 3500/61 is the variant with recorder outputs

Module Form: Full‑height rack‑mount module

Weight: 0.80 kg

Dimension: 241 mm×24.4 mm×242 mm

Protection Grade: IP20

Certification: UL,CSA,CE

Working Temperature: ‑30℃ ~ +65℃,non‑condensing

Storage Temperature: ‑40℃ ~ +85℃

Humidity: 5%‑95% non‑condensing

Application: Turbine,compressor,pump,fans rotating machinery monitoring,bearing metal temperature,stator temperature and process temperature acquisition,3500 rack system maintenance and spare‑part replacement.

Product Details

3500/60 is a six‑channel full‑height temperature monitor module for Bently Nevada 3500 machinery protection rack. It accepts RTD and thermocouple sensor signals,channels can be configured for mixed‑type input through 3500 rack configuration software.

It measures absolute temperature and calculates differential temperature values. Users can set independent alert and danger alarm thresholds for each channel. Isolated I/O version provides 250 Vdc channel‑to‑channel isolation to resist external field interference. This module complies with API 670 machinery protection standard,mainly used for bearing bush temperature,motor stator temperature and key process temperature monitoring.

It does not provide recorder analog outputs. If recorder output function is required,please select 3500/61 module. For TMR triple‑modular‑redundant applications,three temperature monitor modules shall be installed adjacently for voting logic operation.

Note: This is legacy 3500 series spare component,widely used for replacement of turbine and compressor TSI monitoring & protection systems.
