BFR5K150SK2PTS12 Cartridge Flow Control Valve Unit

Module Feature

BFR5K150SK2PTS12 is a screw-in cartridge flow control valve for industrial hydraulic systems.

It adopts cartridge insert design for installation inside standard valve manifold cavity. It is equipped with built-in pressure compensator to keep stable flow output when upstream pressure fluctuates. The model integrates pressure and temperature test ports for on-site inspection and adjustment. It is widely used in hydraulic stations, plastic injection equipment and metal forming machinery for flow regulation and speed control of hydraulic actuators.

Working principle

The internal spool and compensator assembly automatically adjust the opening gap.

When inlet pressure changes, the compensator spool moves to maintain constant pressure difference across the fixed orifice, so the output flow keeps stable regardless of load variation. The adjustment screw can set the required flow rate according to process demand.

Onboard components

Valve sleeve, metering orifice spool, pressure compensator spring, adjusting screw, O-ring sealing set, pressure/temperature test passage.

LED indicators

Not applicable.

Hardware self‑diagnosis

No built-in electronic self-test. The performance is checked by pressure gauge, flow meter and actuator running speed.

Programming software

Not applicable.

Electrical & Process Parameters

Model:BFR5K150SK2PTS12 Device type:Cartridge flow control valve Function:Pressure compensated constant flow regulation for industrial hydraulic circuits

Mechanical & Structure

Mounting:Screw into hydraulic manifold standard cavity Protection class:IP65 Housing:High strength alloy steel with surface anti-corrosion treatment

Environmental

Operating temperature:-10℃ ~ +80℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE, ISO1219

Status:Original hydraulic cartridge valve spare

Installation

Clean the manifold cavity thoroughly before installation. Install the O-ring, screw the cartridge valve into cavity and torque to specified value, set flow rate after oil circulation.

InterfaceMain oil inlet/outlet, pressure test port, temperature test port, flow adjustment screw.

Diagnostic

Flow unstable: Contaminated hydraulic oil, stuck compensator spool or damaged sealing ring. No flow adjustment: Adjustment screw locked or orifice blocked by impurities. External leakage: O-ring aging or insufficient thread torque.

Product Brief

BFR5K150SK2PTS12 cartridge flow control valve, pressure compensated insert hydraulic valve for industrial hydraulic manifold replacement.
