Emerson KJ2005X1-MQ1 Serial Communication Card Unit

Module Feature

KJ2005X1-MQ1 is a serial communication interface card used in Emerson DeltaV distributed control system.

It provides multiple serial ports for connecting field instruments and third-party devices to the DeltaV control network. The card converts serial data into the DeltaV communication protocol, enabling data exchange between external equipment and the control system. It supports standard industrial serial communication modes and is configured through DeltaV engineering software. Widely stocked as maintenance spare for power plant, chemical and oil & gas DCS cabinet.

Working principle

External serial devices transmit data to the card through RS232/RS485 interface.

The onboard communication processor formats the serial frames and forwards them to the DeltaV controller over the control network. Conversely, data from the control system is converted back to serial format for external devices. The card continuously supervises each serial channel and reports link status to the control system.

Onboard components

Serial communication processor, RS232/RS485 transceiver, protocol conversion circuit, control network interface, status LED bank, configurable jumper and printed circuit board.

LED indicators

Front panel LEDs indicate power, link, transmit and receive status for each serial channel.

Hardware self‑diagnosis

Internal circuit monitors serial link health, network connection and board power supply. Configuration is completed by DeltaV engineering software.

Programming software

DeltaV Explorer, used for serial port parameter setup, protocol selection and communication configuration.

Electrical & Process Parameters

Model: KJ2005X1-MQ1 Brand: Emerson Device type: DeltaV serial communication interface card Function: Serial data exchange between external devices and DeltaV control system

Mechanical & Structure

Mounting: Slot mount inside DeltaV control cabinet Protection class: IP20 Housing: Printed circuit board assembly

Environmental

Operating temperature: 0℃ ~ +60℃ Storage temperature: -40℃ ~ +85℃ Ambient humidity: 5~95% non‑condensing

Certification: CE Status: Original Emerson DCS spare

Installation

Cut off cabinet power before replacement.

Insert card into DeltaV slot, connect serial cables and control network, configure serial parameters in DeltaV Explorer, test data communication after commissioning.

Interface

RS232/RS485 serial port terminals, control network interface, board slot connector.

Diagnostic

No serial link: Cable wiring error, baud rate mismatch. Communication fault: Protocol parameter incorrect, address conflict. Board fault alarm: Network interface damaged, power supply abnormal.

Product Brief

KJ2005X1-MQ1 card, Emerson DeltaV serial communication interface card spare for DCS cabinet external device connection replacement.
