Extreme Networks 10GBASE-X 10 Gigabit Ethernet PHY Family

Technical SpecificationsModel：10GBASE-X Brand：Extreme Networks Product Type：10Gigabit Ethernet Physical Layer standard suite

Standard: IEEE 802.3ae Data Rate:10.3125 Gbps Available variants under 10GBASE-X:

• 10GBASE-SR: 850nm multimode fiber, OM3 up to 300m / OM4 up to 400m

• 10GBASE-LR:1310nm single-mode fiber,10km

• 10GBASE-ER:1550nm single-mode fiber,40km

• 10GBASE-SW / LW / EW: WAN PHY versions for SONET/SDH Interface form factor: SFP+, XFP Duplex: Full duplex only Monitoring: DOM available on SFP+ transceivers Hot swap: Yes for pluggable modules Operating temperature：0℃ ~ +70℃ (commercial grade)

System compatibility

10GBASE-X series transceivers are Extreme original optical modules. Compatible with Extreme devices with SFP+ / XFP ports, such as Summit X670, SLX9850, X870 platforms. EEPROM pre-programmed for ExtremeXOS and SLX-OS identification.

Function

10GBASE-X defines the physical layer for 10G Ethernet over optical fiber. It separates multiple sub-standards for different transmission distances. These 10G modules are widely used in data center leaf-spine, campus backbone and enterprise core network. WAN PHY variant can interwork with SONET/SDH transport equipment.

Installation

Insert SFP+/XFP transceiver into device port. Connect corresponding fiber patch cord (multimode for SR, single-mode for LR/ER). Verify module detection and link status via ExtremeXOS/SLX-OS CLI. Configure port to 10G full duplex.

InterfaceSFP+ / XFP gold finger connector, duplex LC optical port, status LED indicators for Extreme Networks 10GBASE-X transceivers.

FeatureOriginal Extreme Networks 10GBASE-X family 10G fiber PHY modules,multiple reach options,full duplex 10.3125Gbps,DOM monitoring,hot-swappable. This spare series is used for enterprise and data center 10G fiber backbone interconnection.

DiagnosticModule undetected: Re-seat transceiver, check host firmware compatibility. Link down: Confirm matching fiber type and wavelength, clean fiber end face, check polarity. Link flapping: Check fiber bend radius, reduce optical attenuation, verify port duplex setting. DOM alarm: Check module temperature, supply voltage and optical power.

Product Brief10GBASE-X is Extreme Networks 10Gigabit Ethernet fiber physical layer suite including SR/LR/ER variants,classic spare for data center and campus 10G fiber backbone links.
