Extreme Networks 210-12p-GE2 Gigabit PoE+ Access Switch

Technical SpecificationsModel：210-12p-GE2 Brand：Extreme Networks Product Type：1U compact fanless gigabit managed access switch

Front Ports:

• 12 × 10/100/1000BASE-T PoE+ RJ45 ports (IEEE802.3af/at), total PoE budget 123W

• 2 × 100/1000BASE-X SFP fiber uplink ports

• 1 × RJ45 serial console port for local CLI management

• 1 × 10/100BASE-T out-of-band management port

Switch Fabric: 28 Gbps Forwarding Rate: 20.8 Mpps Max Jumbo Frame: 9216 bytes VLAN Quantity: Up to 1024 VLANs MAC Address Table: 16K MAC entries ACL: 100 ACL lists, up to 1023 rules per list QoS: 8 hardware priority queues per port CPU & Memory: 400MHz ARM Cortex-A9,512MB DRAM,128MB Flash Power Supply: Built-in AC power input, 100-240V AC Cooling: Fanless silent design Software OS: 210-series firmware, support ExtremeCloud cloud management Operating temperature：0℃ ~ +40℃ Mounting: 19-inch rack mount or desktop installation Dimension: 43mm(H) × 209mm(W) × 255mm(D) Weight: 1.93 kg Status LED: System, PoE, port link/activity indicators

System compatibility

210-12p-GE2 belongs to ExtremeSwitching 210 series. Compatible with Extreme certified 1G SFP transceivers. Supports Layer2 switching and basic IPv4 static routing. Can be managed locally via CLI or remotely through ExtremeCloud cloud platform. It is designed for small and medium enterprise, branch office and classroom network access deployment.

Function

210-12p-GE2 is a silent fanless PoE+ gigabit access switch for SMB and branch networks. 12 PoE+ copper ports deliver data and power for wireless APs, IP cameras and VoIP phones. Two SFP slots provide fiber uplink to aggregation switch, extending transmission distance. It supports VLAN, RSTP/MSTP, 802.1X port authentication, LLDP, QoS and security filtering. Fanless design eliminates fan noise, suitable for office, classroom and quiet working environment. Widely used for small office wired network, wireless AP access and IP video surveillance system.

Installation

Mount the switch on 19-inch rack or place on desktop. Connect AC power cord. Use console cable for initial local configuration. Insert 1G SFP transceiver and fiber patch cord for uplink connection. Configure VLAN, PoE power priority and cloud management parameters according to network requirement. Verify port status and PoE power supply after power-on.

Interface12 PoE+ RJ45 gigabit ports,2 SFP 1G uplink slots,serial console port,out-of-band management port,AC power inlet and status LED indicators for Extreme Networks 210-12p-GE2.

FeatureOriginal Extreme Networks 210-12p-GE2 PoE+ gigabit access switch,12×PoE+ RJ45 ports,2×1G SFP uplink,fanless silent design,support ExtremeCloud cloud management,L2 switching and basic IPv4 routing,802.1X authentication and QoS. This spare is used for SMB,branch office and IP camera access network upgrade and replacement.

DiagnosticSwitch no power: Check AC power cable and wall outlet voltage. PoE port no power: Check PoE budget remaining, port PoE enable status and cable quality. SFP uplink no link: Verify SFP module compatibility, fiber end face cleanliness and optical power. Cloud offline: Check management network connectivity and firmware version. Port link flapping: Inspect copper/fiber cable, auto-negotiation configuration and peer device status.

Product Brief210-12p-GE2 is Extreme compact fanless 12-port PoE+ gigabit access switch with 2 SFP uplink ports,classic spare for small enterprise and branch wired access network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
