Extreme Networks 4050-00042-01 Hot-Swap Fan Module

Technical SpecificationsModel：4050-00042-01 Brand：Extreme Networks Product Type: Hot-swappable fan module for network switch

Airflow Direction: Front-to-back Compatible Platform: X870 series switches Installation: Hot swappable, replace without powering down host switch Status LED: Built-in fault indicator LED Operating temperature：0℃ ~ +45℃ Mechanical: Standard slot insertion with captive screws Weight: 0.42 kg

System compatibility

4050-00042-01 is dedicated cooling spare for Extreme X870 series switches. Matches the front-to-back airflow version of X870 chassis. Can be replaced online without powering off the host switch. Multiple fan modules work together for chassis thermal management.

Function

4050-00042-01 is a hot-swappable fan assembly providing forced air cooling for X870 series high-performance data center switches. It dissipates heat generated by switch chipset, power supply and circuit board to maintain stable operating temperature. Fan module with fault LED can quickly alert fan failure alarm. Hot swap design allows field maintenance without interrupting network service. Widely used for data center switch routine maintenance and faulty fan replacement.

Installation

Identify the failed fan slot on X870 switch. Unscrew the captive screws and pull out the old fan module. Insert new 4050-00042-01 module fully into slot, tighten captive screws. Verify module status LED via switch ExtremeXOS CLI, confirm fan running normally.

InterfaceFan unit, fault status LED, captive screws, internal power and signal connector for Extreme Networks 4050-00042-01.

FeatureOriginal Extreme Networks 4050-00042-01 fan module,hot swappable design,front-to-back airflow,specially for X870 series switches,built-in fault LED indicator. This spare is used for data center X870 switch cooling system maintenance and replacement.

DiagnosticFan module not detected: Confirm fully seated module and tighten captive screws, check connector contact. Fan no rotation: Check module power supply, inspect fan blade blockage. Fan alarm trigger: Check dust accumulation, verify airflow direction matches chassis requirement. Abnormal noise: Inspect fan blade damage or foreign objects inside module.

Product Brief4050-00042-01 is Extreme hot-swappable front-to-back fan spare for X870 data center switches,classic maintenance spare for chassis cooling.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
