Extreme Networks 5520-48W PoE+ Stackable Gigabit Switch

Technical SpecificationsModel：5520-48W Brand：Extreme Networks Product Type：1U rack mount managed PoE+ gigabit edge access switch

Front Ports:

• 48 × 10/100/1000BASE-T RJ45 PoE+ ports (IEEE802.3at, max 30W per port), MACsec supported

• 8 × 1/10G SFP+ uplink ports, support stacking function, MACsec supported

• 1 × RJ45 serial console port

• 1 × USB Micro-B console port

• 1 × USB Type-A port for firmware upgrade and storage

Switch Fabric: 240 Gbps Forwarding Rate: 178.6 Mpps Max Jumbo Frame: 9216 bytes VLAN Quantity: Up to 4094 VLANs MAC Address Table: 64K MAC entries Security: Full-port hardware MACsec encryption QoS: 8 hardware priority queues per port Total PoE Budget: 1440W Power Supply: Dual hot-swappable AC power supplies,100-240V AC input,redundant power support Cooling: Variable speed fans Software OS: Fabric Engine,stackable up to 8 switches Operating temperature：0℃ ~ +50℃ Mounting: Standard 19-inch 1U rack mount Weight: 7.6 kg Status LED: System, PoE power, stack ID, per-port link/activity indicators

System compatibility

5520-48W belongs to Extreme 5520 high-performance edge switch series. It can stack with other 5520 series switches, maximum 8 units in one stack and managed by single IP address. Compatible with Extreme certified 1G/10G SFP+ transceivers and DAC cables. Supports Layer2 switching and complete Layer3 routing protocols, hardware MACsec link encryption. Suitable for large enterprise campus, high-density Wi-Fi AP, IP camera and VoIP terminal access deployment.

Function

5520-48W is high-density PoE+ gigabit access switch for modern enterprise networks. 48 PoE+ ports transmit data and supply up to 30W power for wireless APs, IP surveillance cameras and VoIP phones. Eight SFP+ multi-speed ports provide 1G or 10G fiber uplink to aggregation switch, and support high-speed stacking. Full-port MACsec realizes layer-2 link encryption to protect sensitive network data. It supports VLAN, MSTP/RSTP, 802.1X authentication, LLDP, hardware ACL and multi-level QoS traffic scheduling. Widely used for campus wireless coverage, office building monitoring network and branch wired access.

Installation

Mount the switch to standard 19-inch rack. Install dual hot-swappable AC power supplies and connect power cords. Use console port for initial CLI configuration. Insert SFP+ transceiver or DAC cable for uplink and stacking connection. Configure stacking group, PoE power priority allocation, VLAN and MACsec security policies. Verify port link, PoE output and stack health after power on.

Interface48 PoE+ RJ45 gigabit ports,8 SFP+ 1/10G uplink/stack slots,RJ45 serial console,USB Micro-B console,USB-A port,dual PSU bays and system LED indicators for Extreme Networks 5520-48W.

FeatureOriginal Extreme Networks 5520-48W PoE+ gigabit switch,48×30W PoE+ RJ45 ports,8×1/10G SFP+ ports,1440W total PoE budget,hot-swappable redundant power supply,stackable up to 8 units,full-port MACsec encryption,hardware ACL. This spare is used for enterprise high-density wireless access and edge network upgrade & replacement.

DiagnosticSwitch no power: Check AC input voltage, power supply seating and power cable integrity. PoE port no power: Check remaining PoE budget, PoE enable status and RJ45 cable quality. SFP+ uplink no link: Verify SFP module compatibility, fiber end face cleanliness and DDM optical power. Stacking abnormal: Confirm same firmware version for all stack members and stacking cable integrity. MACsec negotiation fail: Ensure matching security key configured on both ends of the link. Port link flapping: Inspect copper cable, connector damage and peer device auto-negotiation setting.

Product Brief5520-48W is Extreme 1U 48-port PoE+ stackable gigabit switch with eight 10G SFP+ uplink ports,classic spare for enterprise high-density wireless access network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
