Extreme Networks 800125-00-08 10GBASE-SR SFP+ Transceiver

Technical SpecificationsModel：800125-00-08 Brand：Extreme Networks Product Type: Hot-pluggable SFP+ optical transceiver

Standard: 10GBASE-SR Wavelength: 850 nm Fiber Type: Multi-mode fiber (OM3 / OM4) Max Reach:

• OM3: 300 m

• OM4: 400 m Connector: LC duplex Encoding: 64B/66B Data Rate: 10.3125 Gbps DDM: Digital Diagnostic Monitoring supported Operating temperature：0℃ ~ +70℃ Power Consumption: <1W Weight: Approx 0.02 kg Compliance: SFP+ MSA compliant

System compatibility

800125-00-08 is Extreme original 10G SR SFP+ optical transceiver. Compatible with Extreme switches series: 5320,5520,5720,7100,7720 and other platforms with SFP+ slots. Also works with MSA compliant third-party network hardware. Used for 10G short-distance multi-mode fiber uplink within rack or wiring closet.

Function

800125-00-08 is short-range 10G SFP+ optical transceiver. It converts electrical signal from switch SFP+ port to optical signal over multi-mode fiber for 10G Ethernet transmission. DDM function can monitor real-time temperature, transmit optical power, receive optical power and supply voltage. Widely applied in data center rack-to-rack interconnection, enterprise wiring closet short-distance 10G uplink.

InstallationTake ESD protection. Insert the SFP+ module firmly into SFP+ slot of network switch. Plug LC duplex fiber patch cord. Verify module identification and link status via switch CLI. Check optical power value by DDM command.

InterfaceLC duplex fiber port, gold edge contact pin, module status indicator for Extreme Networks 800125-00-08.

FeatureOriginal Extreme Networks 800125-00-08 10GBASE-SR SFP+ transceiver,850nm VCSEL laser,multi-mode fiber,DDM diagnostic function,hot pluggable,MSA standard. This spare module is used for short-distance 10G multi-mode fiber interconnection.

DiagnosticModule undetected: Confirm SFP+ slot support, re-seat transceiver, check firmware compatibility. Link down: Check fiber continuity, LC connector cleaning, match OM3/OM4 multi-mode fiber. Abnormal optical power: Read DDM data, inspect laser aging and fiber attenuation. High temperature warning: Check ambient temperature of equipment cabinet.

Product Brief800125-00-08 is Extreme 10GBASE-SR SFP+ multi-mode optical transceiver,classic spare for short range 10G fiber LAN and data center rack interconnection.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
