Extreme Networks AIO-DQ15021-RP Sector Directional Antenna

Technical SpecificationsModel：AIO-DQ15021-RP (AIO-DQ15021-RPSMA) Brand：Extreme Networks Product Type: Indoor sector directional high-gain WiFi antenna

RF Ports: 4 × RPSMA female connectors Frequency Band: 4900–5950 MHz (5GHz band) Gain: 15 dBi Horizontal Beamwidth: 21° Vertical Beamwidth: 20° Cable Length: 36 inch integrated cable Enclosure: Weather resistant casing, support indoor / light outdoor installation Operating temperature：-40℃ ~ +65℃ Weight: Approx 1.9 kg Mounting: Wall / pole mounting bracket included Warranty: 1 year

System compatibility

AIO-DQ15021-RP is Extreme dedicated sector antenna, mainly compatible with Extreme AP510e wireless access point. Managed by ExtremeCloud IQ controller. It is designed for high-density venue coverage and matches 4 radio ports on AP510e.

Function

AIO-DQ15021-RP is narrow-beam high gain sector antenna for stadium, arena and large hall high density Wi-Fi deployment. The 21° narrow horizontal beam focuses RF signal to target coverage zone, reduces co-channel interference, improves concurrent user capacity. 4 ports connect directly to multi-radio AP to support high-density client access. Integrated short cable with RPSMA connector simplifies field installation. Widely used for stadium, exhibition hall, auditorium high-capacity wireless coverage.

InstallationSelect mounting position and install pole/wall bracket. Fix antenna and adjust azimuth angle to align target coverage area. Connect 4 RPSMA cables to corresponding antenna ports of AP510e. Verify RF signal and wireless coverage after power-up of access point.

Interface4 × RPSMA female connectors, integrated 36-inch RF cables, mounting flange bracket for Extreme Networks AIO-DQ15021-RP.

FeatureOriginal Extreme Networks AIO-DQ15021-RP sector antenna,15dBi high gain,21° narrow beam,4-port design,RPSMA interface,included mounting hardware,optimized for stadium high-density Wi-Fi deployment. This spare antenna is used for large venue wireless coverage upgrade and interference suppression.

DiagnosticNo wireless signal: Check RPSMA connector tightness, inspect cable damage, confirm AP radio enable status. Weak coverage: Adjust antenna azimuth and tilt angle, check cable insertion loss. High interference: Fine tune antenna direction to reduce signal leakage into adjacent sectors. Cable damage: Replace integrated cable assembly if outer jacket or inner conductor broken.

Product BriefAIO-DQ15021-RP is Extreme 15dBi 5GHz 4-port sector directional antenna with 21-degree beam width,classic spare for stadium and large venue high density Wi-Fi coverage.
