Extreme Networks AL590006X-E6 VSP8400 10G SFP+ Line Card

Technical SpecificationsModel：AL590006X-E6 Brand：Extreme Networks (Legacy Avaya) Product Type: Hot-swappable I/O line card for VSP8400 modular chassis switch

Front Ports:

• 6 × SFP+ slots, support 1GBASE-X /10GBASE-X transceivers and DAC cables

• Per-port link/activity LED indicators, module status LED

Max Jumbo Frame: 9216 bytes VLAN Quantity: Up to 4094 VLANs Routing: Hardware IPv4 / IPv6 L3 forwarding QoS: 8 hardware priority queues per port Power Consumption: 95W Software OS: VOSS Operating temperature：0℃ ~ +40℃ Installation: Hot-swappable, insert into VSP8400 chassis slot Weight: Approx 0.42 kg

System compatibility

AL590006X-E6 is dedicated line card for Extreme VSP8400 chassis core switch. Compatible with VSP8400 series chassis, works with Extreme/Avaya certified SFP+ optical transceivers and 10G DAC/AOC cables. Supports Fabric Connect, static and dynamic routing protocols. Designed for campus core aggregation and data center edge chassis expansion.

Function

AL590006X-E6 is modular 10G I/O expansion card for VSP8400 chassis switch. It adds six SFP+ multi-speed ports for 1G or 10G fiber uplink to access switches, servers or storage devices. It provides hardware wire-speed Layer2 switching and Layer3 routing. Hot-swappable design allows replacement without powering down the whole chassis. Widely used for large campus core network, enterprise aggregation chassis port expansion and network upgrade.

InstallationFollow ESD protection procedure. Insert the line card into empty VSP8400 chassis slot and tighten retaining screws. Install SFP+ transceiver or DAC cable. Verify card recognition and port status via VOSS CLI, configure VLAN, routing or Fabric Connect as required.

Interface6 × SFP+ cages, module and port status LED, backplane connector, captive retaining screws for Extreme Networks AL590006X-E6.

FeatureOriginal Extreme Networks AL590006X-E6 VSP8400 line card,6×1/10G SFP+ ports,hot-swappable design,hardware L2/L3 forwarding,VOSS Fabric Connect support. This spare module is used for VSP8400 chassis port expansion and core network maintenance.

DiagnosticCard not detected: Confirm fully seated line card, check screw tightness and compatible VOSS firmware version. SFP+ port link down: Verify transceiver compatibility, clean fiber end, check DDM optical power readings. Fabric Connect failure: Ensure matching IS-IS and VLAN configuration on peer network devices. Overheat alarm: Check chassis fan operation and internal airflow.

Product BriefAL590006X-E6 is Extreme hot-swappable 6-port 10G SFP+ line card for VSP8400 modular chassis switch,classic spare for campus core aggregation port expansion.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
