Extreme Networks AN01463 Analog Control Board

Technical SpecificationsModel:AN01463 Brand:Industrial General Spare Product Type:Printed circuit control board Function:Analog signal sampling, signal conditioning and transmission Signal type:4-20mA / 0-10V analog input and output Operating voltage:24V DC Operating temperature:0℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:0.32kg

System compatibilityAN01463 is a universal analog signal control board widely used in industrial automation systems. It can be matched with PLC, DCS, servo and field sensors for analog data collection and transmission. Widely used for equipment maintenance and overhaul spare parts.

FunctionAN01463 is an industrial analog signal processing board. It collects analog signals from field transmitters and sensors, performs filtering and conditioning, then transmits processed signals to the main controller. It supports overvoltage and overcurrent protection. It monitors signal quality and sends fault alarm when signal loss or abnormal value occurs. Used for factory process monitoring and analog closed-loop control.

InstallationMount the board on DIN rail or chassis slot. Connect 24V DC power supply. Wire field sensor analog signal cables to the terminal block. Connect communication cable to the main controller. Power on and verify signal reading before commissioning.

Interface24V DC power terminal, analog signal input terminals, analog output terminals, status LED indicators, ground terminal for AN01463.

FeatureOriginal AN01463 analog control board, robust EMC anti-interference design, built-in signal filtering circuit, overvoltage/overcurrent protection, on-board diagnostic LED, easy field replacement. This spare supports industrial process analog signal acquisition and monitoring.

DiagnosticBoard no power: check 24V DC power supply and wiring. No analog signal: check sensor wiring, loop power and terminal contact. Signal unstable: inspect grounding, shielding cable and nearby high-frequency interference source. Over-temperature alarm: check ventilation and dust buildup on circuit board.

Product BriefAN01463 industrial analog control board for analog signal acquisition and conditioning, universal automation spare part for factory equipment maintenance.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
