Extreme Networks AP-7632-680B40-US WiNG Indoor Wireless Access Point

Technical SpecificationsModel：AP-7632-680B40-US Brand：Extreme Networks Product Type: Indoor dual-band 802.11ac Wave2 WiNG wireless access point

Radio & WLAN Standard:

• 2.4GHz: 802.11b/g/n, 2×2 MIMO

• 5GHz: 802.11ac Wave2, 2×2 MIMO

• Aux radio: BLE 4.2 for location beaconing Antenna: 5 built-in internal antennas (2×4dBi 2.4GHz,2×6dBi 5GHz,1×BLE antenna) Ethernet Port: 1 × 10/100/1000BASE-T Gigabit RJ45 uplink port PoE: IEEE802.3af PoE class 3; optional 12VDC external power adapter Console: RJ45 console port for local management Max Power Consumption: 11W typical Security: WPA2/WPA3, 802.1X authentication, built-in WIPS wireless intrusion detection Management: WiNG controller / ExtremeCloud IQ Mounting: Ceiling T-bar mount or wall mounting bracket (sold separately) Operating temperature：0℃ ~ +40℃ Storage temperature：-50℃ ~ +70℃ Humidity: 0~95% non-condensing Weight: Approx 0.52 kg Regulatory: US radio domain

System compatibility

AP-7632-680B40-US belongs to Extreme WiNG AP7632 indoor AP family. Managed by WiNG virtual hardware controller or ExtremeCloud IQ cloud platform. Compatible with standard 802.3af PoE gigabit switches. Supports roaming with other WiNG series access points.

Function

AP-7632-680B40-US is indoor 802.11ac Wave2 wireless access point for enterprise office, classroom and retail store Wi-Fi coverage. Dual-band 2x2 MIMO radios serve Wi-Fi clients, built-in BLE radio delivers beacon for indoor location service. Single GE uplink connects to PoE switch, powered by 802.3af. Integrated WIPS detects rogue access points and wireless threats. Supports seamless client roaming between APs. Widely deployed for office, retail, hospital and school indoor wireless network.

InstallationApply ESD protection. Install ceiling T-bar or wall mounting bracket. Mount AP onto bracket. Connect CAT5e/CAT6 cable to GE port and supply 802.3af PoE power. Complete AP adoption on WiNG controller / ExtremeCloud IQ, configure SSID, RF profile and security policy. Verify client association and wireless coverage after power-up.

Interface1×GE RJ45 PoE port, RJ45 console port, reset button, multi-color status LED for Extreme Networks AP-7632-680B40-US.

FeatureOriginal Extreme Networks AP-7632-680B40-US indoor WiNG access point,2x2:2 dual band 802.11ac wave2,internal antenna,BLE location beacon,802.3af PoE,built-in WIPS security. This spare AP is used for enterprise indoor wireless coverage deployment and replacement.

DiagnosticAP not discovered: Check PoE power, cable continuity, confirm controller network reachability. No SSID broadcast: Verify AP adopted by controller, enable WLAN profile on radio. Poor wireless speed: Check channel planning, reduce RF interference, inspect client signal level. BLE location inaccurate: Check AP mounting height and surrounding metal obstacles. LED fault indicator: Reboot AP, verify firmware version match controller.

Product BriefAP-7632-680B40-US is Extreme WiNG indoor 2x2 MIMO 802.11ac Wave2 AP with BLE beacon,classic spare for enterprise office and retail indoor wireless coverage.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
