Extreme Networks AP510I-FCC AP510i Wi-Fi 6 Indoor Wireless Access Point

Technical SpecificationsModel：AP510I-FCC Brand：Extreme Networks Product Type: Indoor Wi-Fi 6 (802.11ax) tri-radio wireless access point

Radio & WLAN Standard:

• Radio 1: 2.4GHz / 5GHz dual band,4×4 MIMO

• Radio 2: 5GHz dedicated radio,4×4 MIMO

• IoT Radio: 2.4GHz BLE beacon radio for indoor positioning Antenna: 8 built-in Wi-Fi internal antennas +1 integrated BLE antenna Ethernet Ports:

• GE1: 100M/1G/2.5G/5GBASE-T RJ45,PoE input

• GE2: 10/100/1000BASE-T RJ45 PoE: Support IEEE802.3af / 802.3at; optional 12VDC external DC power Console: RJ45 console port for local maintenance Max Clients: Up to 1024 total connected clients Security: WPA3,802.1X,WIPS wireless intrusion prevention,TPM secure boot Management: ExtremeCloud IQ,WiNG / VX / NX on-prem controller Mounting: Ceiling T-bar bracket,wall mount compatible Operating temperature：0℃ ~ +40℃ (sea level) Weight: Approx 0.72 kg Regulatory: FCC US radio domain

System compatibility

AP510I-FCC belongs to Extreme AP510 series indoor Wi-Fi6 access point family. Managed by ExtremeCloud IQ cloud controller or local WiNG VX/NX controllers. Compatible with PoE 802.3af/at multi-gig switches. Supports seamless roaming with AP5xx series access points.

Function

AP510I-FCC is high-performance indoor Wi-Fi6 enterprise access point with built-in antennas. Tri-radio architecture can work in multiple operation modes: dual service radio (2.4G+5G), dual 5GHz high-density mode or sensor scanning mode. GE1 port supports up to 5G multi-gig uplink to match high Wi-Fi6 throughput. BLE radio provides indoor location beaconing for asset tracking. Supports WPA3 latest wireless security and built-in WIPS to detect rogue APs. Widely deployed in classrooms, stadiums, retail malls, hospitals and office high-density wireless coverage.

InstallationPerform ESD protection. Install ceiling T-bar or wall mounting bracket. Fix AP onto bracket. Connect CAT5e/CAT6A cable to GE1 port and supply PoE power. Complete AP adoption on ExtremeCloud IQ or local controller, configure SSID, RF profile and security policy. Verify client association and wireless coverage after power-up.

Interface5G multi-gig GE1 port, GE2 gigabit port,RJ45 console port,reset button,multi-color LED indicators for Extreme Networks AP510I-FCC.

FeatureOriginal Extreme Networks AP510I-FCC indoor Wi-Fi6 access point,tri-radio 4x4:4 MIMO,internal antenna,5G multi-gig uplink,WPA3 security,FCC US domain,high concurrent client capacity. This spare AP is used for enterprise high-density indoor wireless network deployment and replacement.

DiagnosticAP not discovered: Check PoE power supply, cable quality, confirm controller network reachability. No SSID broadcast: Confirm AP adopted by controller, enable WLAN profile on target radio. Low wireless throughput: Verify multi-gig negotiation status,optimize channel planning and reduce RF interference. Positioning inaccuracy: Check BLE radio enable status,avoid large metal obstacles around AP. Radio unstable: Verify firmware consistency with controller,check ambient cabinet temperature.

Product BriefAP510I-FCC is Extreme AP510i indoor Wi-Fi6 tri-radio 4x4 MIMO access point with internal antennas and FCC certification,classic spare for enterprise high-capacity indoor wireless coverage.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
