Extreme Networks BR-SLX9850-10Gx72S-M Interface Line Card

Technical SpecificationsModel：BR-SLX9850-10Gx72S-M (short name BR-SLX9850-10G) Brand：Extreme Networks (Former Brocade) Product Type：Hot-swappable modular routing line card for SLX 9850 chassis

Port Configuration: 72 × 1000BASE-X / 10GBASE-X SFP+ dual-speed ports,hot-pluggable Front panel LED indicators per port High-speed backplane edge connector to connect chassis fabric

Switch Performance: Packet buffer:12GB per line card MAC address table: up to 750,000 MAC entries Routing table: 256,000 IPv4 routes,64,000 IPv6 routes Hardware forwarding for IPv4, IPv6 and MPLS

Software: SLX-OS, support EVPN, VXLAN, segment routing, PTP 1588, EAPS Hot swap: Online insertion and removal without chassis power off Operating temperature：0℃ ~ +40℃ Dimension: 64mm(H) ×411mm(W) ×376mm(D) Weight: 5.94kg

System compatibility

BR-SLX9850-10Gx72S-M is dedicated line card for Extreme SLX9850-4 (4-slot) and SLX9850-8 (8-slot) modular routing chassis. SFP+ ports compatible with 1G SFP and 10G SFP+ transceivers such as SR,LR,ER,BiDi optical modules. Managed via chassis management module, can work together with other SLX9850 line cards in same chassis.

Function

BR-SLX9850-10Gx72S-M is high-density 1/10G fiber line card for SLX9850 core router. 72 SFP+ ports provide flexible gigabit or 10-gigabit fiber access for leaf switches, servers and storage devices. It supports hardware MPLS, EVPN/VXLAN virtualization, segment routing and PTP timing synchronization. 12GB large packet buffer absorbs traffic burst and reduce packet loss, suitable for spine-leaf data center architecture. Hot swap design allows maintenance without chassis shutdown.

Installation

Power on SLX9850 chassis, insert line card into empty slot, push fully and tighten captive screws. Insert SFP/SFP+ transceivers and fiber cables. Verify card detection and port status through SLX-OS CLI. Set port speed to 1G or 10G according to optical module type.

Interface1/10G SFP+ port,port status LED,chassis backplane gold finger connector for Extreme Networks BR-SLX9850-10Gx72S-M.

FeatureOriginal Extreme BR-SLX9850-10Gx72S-M hot-swappable 72×SFP+ dual-speed line card for SLX9850 chassis,support 1G/10G auto-sensing,12GB packet buffer,hardware IPv4/IPv6/MPLS,SLX-OS advanced routing feature set. This spare is used for data center high-density 10G fiber access and aggregation port expansion.

DiagnosticModule undetected: Re-seat line card, check slot backplane connector and captive screws, verify SLX-OS firmware compatibility. SFP+ port no link: Confirm compatible SFP/SFP+ transceiver, inspect fiber polarity and optical power budget. Speed negotiation failure: Manually configure port speed to match transceiver, disable auto-negotiation if needed. Buffer congestion alarm: Check burst traffic and adjust QoS queue scheduling. Over-temperature alarm: Inspect chassis fan tray operation and cabinet airflow.

Product BriefBR-SLX9850-10Gx72S-M (BR-SLX9850-10G) is Extreme Networks hot-swappable 72-port 1/10G SFP+ line card for SLX9850 modular router,classic spare for data center 10G fiber aggregation and leaf network expansion.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
