Extreme Networks BR-SLX9850-MM Management Module

Technical SpecificationsModel：BR-SLX9850-MM Brand：Extreme Networks (Former Brocade) Product Type：Hot-swappable chassis management / control module

Processor & Memory: 4-Core Intel CPU RAM: Original version 16GB, upgraded version 32GB Storage: Dual internal SSD for OS, logs and configuration files

Front Panel Interface: 2 × RJ45 out-of-band management ports 2 × RJ45 serial console ports 2 × USB 3.0 ports Status LED indicators for health, active/standby, fault High-speed backplane connector to chassis fabric

Power consumption: 97W Hot swap: Yes, online insertion and removal Redundancy: Support dual MM deployment (active / standby) Software: SLX-OS, manages all line cards, fabric modules, PSU and fan trays Operating temperature：0℃ ~ +40℃ Dimension: 54.5mm(H) ×201mm(W) ×376.386mm(D) Weight: 3.04kg

System compatibility

BR-SLX9850-MM works for SLX9850-4 (4-slot) and SLX9850-8 (8-slot) modular routing chassis. It controls BR-SLX9850 series line cards, SFM fabric modules, power supplies and fan assemblies. Dual MM can be installed for HA redundancy. Note: 16GB older MM only supports SLX-OS up to 18r.2.00; new 32GB MM supports later SLX-OS releases.

Function

BR-SLX9850-MM is the central control brain for SLX9850 router chassis. It hosts SLX-OS operating system, executes routing control plane, manages all hardware FRUs, stores system configuration, logs and firmware images. In dual-MM setup, standby MM automatically takes over control if active MM fails to avoid core network outage. It provides console and OOB management access for remote configuration and troubleshooting.

Installation

Power on SLX9850 chassis, insert BR-SLX9850-MM into dedicated management slot, push fully and tighten captive screws. Connect OOB Ethernet cable and serial console cable. Chassis will recognize the management module automatically. For HA deployment, install a second MM as standby. Verify active/standby role and FRU inventory via SLX-OS CLI.

InterfaceOOB management RJ45 port, RJ45 serial console, USB3.0 port, status LED, chassis backplane gold finger connector for Extreme Networks BR-SLX9850-MM.

FeatureOriginal Extreme BR-SLX9850-MM hot-swappable SLX9850 management module,quad-core CPU,dual SSD storage,support active/standby HA redundancy,2×OOB management + dual console ports,monitors all chassis FRUs,runs SLX-OS. This spare is the main control card replacement for SLX9850 modular core router.

DiagnosticModule undetected: Re-seat MM, tighten captive screws, inspect backplane connector, verify firmware compatibility. Failover abnormal: Confirm both MM firmware versions match, check heartbeat link between active and standby MM. Boot / storage error: Check SSD health status via SLX-OS, verify OS image integrity. High CPU alarm: Inspect routing protocol load, optimize route filtering. Over-temperature alarm: Check chassis fan tray and cabinet airflow.

Product BriefBR-SLX9850-MM is Extreme Networks hot-swappable management controller for SLX9850 modular router, supporting active/standby redundancy,classic spare for data center spine/core router control plane maintenance.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
