Extreme Networks DPS-1100GB-1B Power Supply Unit

Technical SpecificationsModel：DPS-1100GB-1B Brand：Extreme Networks Product Type：Hot-swappable AC power supply unit

Input: 90~264VAC universal input, 50/60Hz Max Output Power: 1100W Main Output: +12V Efficiency: 80Plus Platinum rated Communication: PMBus digital monitoring Cooling: Built-in variable speed fan Hot swap: Yes, support in-service replacement for redundant configuration Protection: Over voltage, over current, over temperature, short circuit protection Airflow: Front-to-back / Back-to-front option (confirm version) Operating temperature：0℃ ~ +50℃ RoHS compliant

System compatibility

DPS-1100GB-1B is Extreme Networks original hot-swap power supply. Compatible with Extreme high-density switches supporting 1100W FRU PSU, such as Summit X series and SLX series platforms. Supports dual PSU active/standby redundancy. The PMBus channel enables ExtremeXOS / SLX-OS to read PSU health, temperature and power consumption.

Function

DPS-1100GB-1B is a high-efficiency 1100W redundant power supply for rack mounted network switches. It supplies stable +12V power to switch mainboard, line cards and fan assemblies. Redundant dual PSU deployment allows single PSU replacement without powering off the whole switch, avoiding core network outage. Built-in intelligent fan adjusts speed according to internal temperature to reduce noise and power waste.

Installation

Power down the PSU bay or use in-service hot swap if redundant. Slide the PSU into dedicated power bay until latch clicks. Connect AC power cable. Verify PSU health status via ExtremeXOS / SLX-OS CLI. Confirm airflow direction matches chassis requirement.

InterfaceBackplane gold finger connector, AC input socket, status LED indicator for Extreme Networks DPS-1100GB-1B.

FeatureOriginal Extreme Networks DPS-1100GB-1B 1100W hot-swappable AC power supply,80Plus Platinum high efficiency,PMBus real-time monitoring,complete multi-protection circuit,support redundant HA deployment. This spare is used for Extreme rack switch power supply replacement.

DiagnosticPSU not detected: Re-seat the power supply, inspect backplane connector. Power fault alarm: Check AC input voltage and power cable connection. Fan / over-temperature alarm: Inspect fan operation, dust buildup and cabinet airflow. Flapping status: Verify proper seating, check for overloading of total system power draw.

Product BriefDPS-1100GB-1B is Extreme Networks 1100W Platinum hot-swappable redundant AC power supply,classic spare for enterprise and data center high power switch replacement.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
