Extreme Networks SSR-PS-8 Power Supply Module

Technical SpecificationsModel：SSR-PS-8 Brand：Extreme Networks Product Type：Hot-swappable modular chassis power supply

Input: 100–240V AC, 50/60Hz Main Output: 12V DC Rated Output Power: 400~500W Cooling: Built-in active cooling fan Hot swap: Yes, supports hot insertion and removal without chassis power off Operating temperature：0℃ ~ +50℃ Weight: approx 2.0kg

System compatibility

SSR-PS-8 is dedicated power module for Extreme / Cabletron FR Smart Switch Router 8-slot chassis. Multiple PSU can be installed in the chassis for redundant power configuration. It works together with various line cards and management modules inside SSR 8000 series chassis. There is also DC variant SSR-PS-8-DC available for DC input environments.

Function

SSR-PS-8 supplies stable 12V DC power to the 8-slot SSR routing chassis and all inserted service modules. Multiple power modules support load balancing and power redundancy. If one PSU fails, remaining working units will take over the full load automatically to avoid network outage. It also provides power status monitoring and fault alarm signals to chassis management system.

Installation

Insert SSR-PS-8 module into the vacant PSU bay of SSR 8-slot chassis, push fully until locking latch clicks. Connect AC power cord. Chassis will detect the new power module automatically. Verify power status via chassis CLI or management console. For HA deployment, install at least two PSU for redundancy.

InterfaceAC power inlet, status LED indicators, chassis backplane gold finger connector for Extreme Networks SSR-PS-8.

FeatureOriginal Extreme SSR-PS-8 hot-swappable modular power supply for 8-slot SSR FR chassis,400~500W,AC input,support multi-PSU load balance and redundancy,built-in cooling fan,real-time power fault monitoring. This spare is used for legacy core SSR router chassis power replacement.

DiagnosticModule undetected: Re-seat the PSU module, inspect backplane connector and locking latch. No power output: Check AC power cord and wall outlet, verify input voltage. Fan / over-temperature alarm: Check fan rotation, clean dust on air intake, reduce ambient cabinet temperature. Redundancy failure: Confirm both PSUs are recognized by chassis and load balancing is enabled.

Product BriefSSR-PS-8 is Extreme Networks hot-swappable AC modular power supply for SSR 8-slot FR Smart Switch Router chassis,classic spare part for legacy core routing chassis power maintenance.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
