Extreme Networks Summit X440-8p Gigabit PoE+ Managed Switch

Technical SpecificationsModel：X440-8p Brand：Extreme Networks Product Type：1U rackmount / desktop Layer2/Layer3 managed PoE+ switch

Ports:

• 8 ×10/100/1000BASE-T auto-sensing RJ45 copper ports, IEEE802.3at PoE+, max 30W per port

• 4 ×100/1000BASE-X SFP fiber slots, transceivers sold separately

• 2 ×dedicated SummitStack stacking ports

• 1 ×10/100BASE-T out-of-band management port

• 1 ×RJ45 serial console port

Switching capacity：64Gbps Forwarding rate：48Mpps MAC address table：32000 entries Jumbo frame：9216 bytes OS：ExtremeXOS Stacking：SummitStack, compatible within X440 series Total PoE power budget：170W

Power & fan：Built-in AC power supply, variable speed smart fans, front-to-back airflow Operating temperature：0℃ ~ +40℃ Storage temperature：-40℃ ~ +70℃ Relative humidity：10%~90%, non-condensing Weight：3.04kg

System compatibility

X440-8p belongs to Extreme Summit X440 stackable edge switch family. Compatible with Extreme validated 100BASE-FX / 1000BASE-X SFP transceivers. Managed via local CLI / web GUI. Widely used for small wiring closet, retail shop, smart building PoE access for wireless APs, IP cameras and IP phones spare replacement.

Function

X440-8p is compact Layer3 gigabit PoE+ access switch. 8 PoE+ RJ45 ports deliver data and power for powered end devices. Four SFP slots provide flexible gigabit fiber uplink. It supports static & dynamic routing, VLAN, STP/RSTP/MSTP, LACP link aggregation, ACL, QoS and multicast protocols. It monitors port link state, PoE power consumption, system temperature and fan health, and generates hardware fault alarms. Used for small site PoE edge access networks.

Installation

Mount the switch on standard 19-inch 1U rack or use desktop rubber pads. Connect AC power cord. Insert SFP transceivers and fiber patch cords for fiber uplink if required. Connect console port for initial configuration and stacking setup. Verify boot,port link and PoE output function before commissioning.

Interface8×PoE+ RJ45 ports,4×GE SFP fiber slots,2×SummitStack ports,out-of-band management port,RJ45 serial console,status LEDs,stack ID indicator,reset button,AC power inlet,ground terminal,rack mounting ears for Extreme Networks Summit X440-8p.

FeatureOriginal Summit X440 compact 1U rackmount Layer3 stackable PoE+ switch,8×802.3at PoE+ ports plus 4 SFP fiber uplink slots,170W PoE budget,ExtremeXOS OS,dedicated stacking ports,smart fan cooling,built-in self-diagnostic function. This spare fits small branch and retail PoE edge network maintenance and upgrade.

DiagnosticSwitch fails to boot: Check AC power input and power supply health. PoE port no power: Verify PoE total budget,PD classification and port admin status. Copper port link down: Inspect RJ45 cable quality and auto-negotiation settings. SFP port no link: Check SFP transceiver,fiber cable and peer device configuration. Low optical power alarm: Dirty fiber endfaces or damaged fiber cables. Transceiver undetected: Confirm Extreme compatible SFP module and correct insertion. Over-temperature alarm: Check fan operation and cabinet ventilation,clean dust buildup. Stack group split: Verify stacking cable and matched ExtremeXOS firmware version.

Product BriefX440-8p is Extreme Networks Summit X440 series compact 1U rackmount Layer3 stackable gigabit PoE+ managed switch with 8 PoE+ RJ45 ports and 4 GE SFP fiber slots,classic spare part for small site PoE edge network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
