Extreme Networks Summit X460-G2-24P-GE Gigabit PoE+ Ethernet Switch

Technical SpecificationsModel：X460-G2-24P-GE Brand：Extreme Networks Product Type：1U Rack Mount Gigabit Ethernet Switch

Front Ports:

• 24 × 10/100/1000BASE-T PoE+ RJ45 copper ports (IEEE802.3af/at)

• 4 × 1000BASE-X SFP fiber uplink ports

• 1 × RJ45 serial console port for local CLI management

• 1 × 10/100/1000BASE-T out-of-band management port

• 1 × USB 2.0 port for firmware upgrade & configuration backup

Rear Panel:

• 1 × VIM versatile interface expansion slot for additional uplink/stacking modules

• 1 × TM-CLK timing slot for SyncE / IEEE1588 PTP clock synchronization

• Dual modular PSU bays, hot swappable

• Hot-swappable fan tray, support front-to-back or back-to-front airflow

Switch Fabric: 296 Gbps Forwarding Rate: 220.2 Mpps Max Jumbo Frame: 9216 bytes VLAN Quantity: Up to 4094 VLANs MAC Address Table: 32K MAC entries ACL: 4096 ingress ACL rules QoS: 8 hardware priority queues per port PoE Budget: Single PSU 715W; dual PSU up to 1440W full PoE+ load CPU & Memory: 1GHz 64-bit MIPS,1GB ECC DDR3,4GB eMMC Flash Software OS: ExtremeXOS Operating temperature：0℃ ~ +50℃ Mounting: Standard 19-inch 1U rack mount Status LED: System power, fan, stack ID, per-port link/activity & PoE status indicators

System compatibility

X460-G2-24P-GE belongs to Extreme X460-G2 series. Supports SummitStack-V virtual stacking, up to 8 switch members in one stack. Compatible with Extreme original 1G SFP transceivers for front uplink slots, rear VIM slot supports VIM2 series interface modules. Supports Layer2 switching and full Layer3 IPv4/IPv6 routing, OSPF, VRRP and multicast routing. SyncE and PTP timing function available when timing module is installed.

Function

X460-G2-24P-GE is a 1U rack-mount high-performance PoE+ switch for enterprise wireless access or aggregation layer. 24 PoE+ RJ45 ports supply data and power for wireless AP, IP camera and VoIP phones. Four fixed 1G SFP uplink ports connect to core switch via fiber links. The rear VIM slot can expand extra 10G/40G high-speed ports. It supports advanced QoS, VLAN segmentation, ACL security filtering, Fabric Attach automated device authentication and broadcast storm control, widely deployed for campus wireless, IP monitoring and medium enterprise network.

Installation

Mount the switch into standard 19-inch equipment rack. Install power supplies and fan tray. Connect AC power cable. Use console cable for initial CLI configuration. Insert 1G SFP transceivers into front SFP slots and connect fiber patch cords. Power off chassis before installing rear VIM expansion module, wear ESD anti-static wrist strap and tighten captive screws. Configure SummitStack-V stacking parameters for multi-switch cluster.

Interface24 PoE+ RJ45 gigabit ports,4 SFP 1G uplink slots,serial console port,out-of-band management port,USB port,rear VIM expansion slot,TM-CLK timing slot,dual PSU bays,fan tray and status LED indicators for Extreme Networks X460-G2-24P-GE.

FeatureOriginal Extreme Networks X460-G2-24P-GE 24-port PoE+ gigabit switch,4×1G SFP uplink ports,rear VIM expansion slot,hot-swappable power supply and fan tray,SummitStack-V stacking,L2/L3 forwarding,jumbo frame,PoE+ power management,SyncE and PTP timing support,ACL and QoS policy control. This spare is used for enterprise wireless access and aggregation network replacement & upgrade.

DiagnosticSwitch no power: Check AC input power cable and voltage, inspect PSU seating and LED status. PoE port no power: Check PoE power budget, port priority configuration and cable quality. SFP uplink no link: Check SFP module compatibility, fiber end face cleanliness and optical attenuation. Stacking failure: Confirm stacking port SummitStack-V working mode, stacking cable integrity and stack member ID. High temperature alarm: Check fan tray operation, dust accumulation and cabinet airflow condition.

Product BriefX460-G2-24P-GE is Extreme Networks 1U stackable 24-port PoE+ gigabit switch with 4×1G SFP uplink and rear VIM expansion slot,classic spare for enterprise wireless and IP camera access & aggregation network.
