Foxboro FBM07A/12A Discrete Input Fieldbus Module

Technical Specifications

Model:FBM07A/12A

Brand:Foxboro

System compatibility:I/A Series DCS legacy FBM fieldbus I/O subsystem

Function:16‑channel discrete DC input fieldbus module,collects 24VDC switch status signals from field limit switches,relay auxiliary contacts,matched with 12‑style termination assembly

Installation:Baseplate‑mount installation,mated with dedicated FBM baseplate and 12‑series termination assembly

Input channel:16‑channel 24VDC discrete input,group‑wise galvanic isolation

Circuit feature:Built‑in hardware filter for contact bounce suppression

Feature:Support hot‑swap online replacement without subsystem power‑off

Diagnostic:Per‑channel status LED indicators,fieldbus communication fault indicator

Power supply:Powered via FBM baseplate backplane,typical power consumption 3W

Protection:Transient surge absorption for each signal channel

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Aluminum alloy metal housing,slot‑in mechanical locking structure

Protection class:IP20

Horizontal operating temperature:0℃ ~ +60℃

Vertical operating temperature:‑20℃ ~ +55℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:0.98kg

Dimensions:36mm ×128mm ×144mm

Certification:CE,UL

MTBF:>83000 hours

Built‑in function

FBM07A/12A discrete input module collects on‑off status signals of field equipment for Foxboro I/A‑Series DCS system. It cooperates with 12‑style termination assembly to complete field‑side wiring connection. Built‑in filter circuit restrains contact‑bounce interference. Hot‑swap supports online module replacement,widely applied for pump,valve interlock‑signal acquisition loops in petrochemical,chemical and power‑plant facilities.

Product Brief

FBM07A/12A belongs to Foxboro I/A Series legacy DCS discrete‑input spare‑part family,obsolete original baseplate‑mount discrete input module component. Must match with corresponding FBM baseplate and 12‑series termination assembly. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
