GE Fanuc IC695310-FT CPU Controller

Technical SpecificationsModel：IC695310-FT Brand：GE Fanuc Product Type: Single-slot plug-in fault tolerant CPU module for PACSystems RX3i universal backplane

Module Feature:Function: High-performance main processor for PACSystems RX3i fault tolerant redundant PLC system, executes control logic, processes I/O data and supports hot standby redundant CPU operation. Processor: High speed embedded processor with floating-point arithmetic Memory: Large battery-backed RAM for user program, variables and data logging Redundancy: Designed for FT (Fault Tolerant) hot standby dual CPU rack configuration, seamless switchover upon primary CPU failure Ports: Dual redundant 10/100Mbps Ethernet ports, serial port Communication protocols: SRTP, Modbus TCP, SNP, EGD Programming software: Proficy Machine Edition Programming languages: Ladder Diagram, Structured Text, Function Block Diagram LED indicators: OK, RUN, FAULT, SYNC, Ethernet status lights Hardware self-diagnosis: memory test, backplane bus check, redundancy synchronization monitoring, internal fault detection FT suffix = Fault Tolerant variant for high availability critical control application

Electrical ParametersBackplane supply:+5VDC, power consumption 3.2W

Mechanical & Structure:Mounting:Plug-in installation into RX3i universal backplane single slot Protection class:IP20 Weight:0.45kg

Environmental:Operating temperature:0℃ ~ +60℃ Ambient humidity:5~95% non-condensing Certification:UL, CE Status:Manufacturer discontinued legacy spare part

System compatibilityIC695310-FT belongs to GE Fanuc PACSystems RX3i family. Compatible with RX3i backplane, power supply, I/O and communication modules. Widely used in power generation, oil & gas, chemical and critical process control requiring fault tolerant redundant PLC.

FunctionIC695310-FT is fault tolerant CPU for GE Fanuc PACSystems RX3i. It supports dual hot standby redundant CPU system. Two synchronized CPUs run same logic simultaneously. If primary CPU fails, system switches to standby CPU without process interruption. Dual Ethernet ports provide redundant network communication. Battery backed memory retains program and process data during power loss. Front LEDs display running status, redundancy sync and fault information.

InstallationFollow lockout/tagout safety procedure before installation. Fully cut off rack power. Insert IC695310-FT into RX3i backplane slot and lock retainer. Connect Ethernet and serial cables. Configure redundant hardware and synchronization settings in Proficy Machine Edition. Power on and verify CPU synchronization and I/O communication.

InterfaceRX3i backplane gold-edge connector,dual 10/100Mbps RJ45 Ethernet port,serial communication port,on-board RUN / FAULT / SYNC LED indicators for GE Fanuc IC695310-FT.

DiagnosticCPU cannot enter RUN mode:Check backplane power, valid downloaded project and redundancy sync configuration. Redundancy sync lost:Inspect sync cable, firmware version matching and backplane contact. Fault LED active:Battery failure, memory error or internal hardware fault.

Product BriefIC695310-FT is GE Fanuc legacy PACSystems RX3i fault tolerant redundant CPU module,supports hot standby dual CPU configuration for high reliability critical industrial control,discontinued PLC controller spare.
