Krohne 10016727 Flow Signal Converter Board

Feature & Principle

It is a dedicated signal amplifier board manufactured by Krohne for electromagnetic flowmeter. It receives the weak induced voltage signal from the flow sensor electrode, filters, amplifies and processes the signal internally, then converts it into standard analog 4-20mA or frequency pulse signal. It supports flow value calculation, empty pipe detection and fault diagnosis, communicates with display unit. It is widely matched with Krohne series magflow sensors for liquid flow measurement.

Specifications

Model: 10016727 Brand: Krohne Function: Flow signal amplification and conversion Output: 4-20mA, pulse/frequency Power supply: 24VDC Installation: Inside flowmeter converter housing Protection: IP67 when assembled completely Application: Water, sewage, chemical liquid electromagnetic flow measurement Certification: CE

Components & Diagnostics

Signal sampling PCB, pre-amplifier circuit, A/D conversion chip, signal output terminal, status indicator. Common faults: no flow signal output, signal jumping, current output deviation, communication failure.

Product Brief

10016727 flow signal converter board, Krohne electromagnetic flowmeter spare widely used for liquid flow meter overhaul and replacement.
