Meggitt 20-12-01-02-01-0 Vibration Sensor

Feature & Principle

It is a piezoelectric vibration sensor manufactured by Meggitt. The internal piezoelectric crystal generates charge signal under mechanical vibration excitation. After signal conditioning, the vibration acceleration signal is output to the monitoring module. It is suitable for continuous vibration detection of bearing housings of fans, pumps, compressors and turbines, to realize equipment condition monitoring and fault early warning.

Specifications

Model: 20-12-01-02-01-0 Brand: Meggitt Measurement type: Vibration acceleration Sensing element: Piezoelectric crystal Mounting: Stud mounting Output: Charge / IEPE optional Protection: Hermetically sealed Application: Petrochemical, power, compressor set vibration monitoring Certification: CE, ATEX optional

Components & Diagnostics

Piezoelectric sensing element, signal conditioning circuit, metal housing, cable connector. Common faults: cable breakage, internal crystal damage, signal loss, zero drift.

Product Brief

20-12-01-02-01-0 vibration sensor, Meggitt rotating machinery condition monitoring spare widely used for compressor and pump overhaul and replacement.
