MWI8104LEA Process Transmitter Unit

Module Feature

MWI8104LEA is a smart loop-powered field transmitter for industrial process measurement.

It supports 4-20mA analog signal superimposed with HART digital communication protocol. It features stable signal output, reverse wiring protection and overvoltage protection. It can be configured remotely for range setting, damping adjustment and tag assignment. It is widely deployed in chemical, water treatment, pulp & paper and power process control loops.

Working principle

Internal sensing element captures physical process variable.

Electronic circuit converts sensor signal into standardized 4-20mA current signal, and embeds HART digital data for two-way communication with host system. DCS or PLC reads real-time measured value and diagnostic information through the HART bus.

Onboard components

Sensing element assembly, signal conditioning PCB, HART communication chip, LCD local display, cable gland terminal block, stainless steel or aluminum instrument housing.

LED indicators

Front LEDs indicate power status, active measurement, fault alarm and communication activity.

Hardware self‑diagnosis

Built-in supervision detects sensor drift, loop open, over-range and internal electronic failure. Fault codes can be viewed on local display or via HART host software.

Programming software

HART configuration tool, used for transmitter range setup, tag editing, trim calibration and fault troubleshooting.

Electrical & Process Parameters

Model:MWI8104LEA Brand:Unconfirmed Device type:Smart HART process transmitter Function:Process variable measurement and signal transmission for industrial automation control system

Mechanical & Structure

Mounting:2-inch pipe bracket or direct process connection Protection class:IP66 Housing:Coated aluminum alloy instrument enclosure

Environmental

Operating temperature:-40℃ ~ +85℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE, HART

Status:Original process instrumentation spare

Installation

Install with proper mounting bracket and avoid vibration and direct thermal radiation.

Connect two-wire loop power and signal cable, set measurement range and damping before commissioning.

Interface

Process connection port, two-wire power and signal cable gland.

Diagnostic

No output signal: Loop power loss, broken cable or internal electronics damage.

Signal drift: Sensor contamination, temperature shock or calibration offset.

HART communication offline: Wrong loop resistance, cable short circuit or communication chip failure.

Product Brief

MWI8104LEA smart transmitter, HART loop-powered field instrument spare for industrial process control pipeline replacement.
