Schneider NW4100T33WP22 Masterpact NW4000 ACB Unit

Module Feature

NW4100T33WP22 belongs to Schneider Masterpact NW high-current air circuit breaker series. It adopts draw-out removable structure, convenient for online inspection and replacement without bus power cut. Equipped with Micrologic electronic protection unit, supports LSI, LSIG multi protection curves, adjustable overload, short-time delay and short-circuit instantaneous protection. 3-pole design, frame rated 4000A, high short-circuit breaking capacity. This version is pre-fitted with communication interface, auxiliary contact and closing/opening coil. Widely stocked as spare for power plant, data center, heavy industry main switchboard and large commercial power distribution system.

Working principle

Current transformers collect three-phase current signals and transmit data to Micrologic trip controller. The internal processor compares measured current with preset protection setting values. Overload condition triggers inverse time delayed trip; short circuit fault triggers fast breaking of main contacts. Closing coil, shunt trip coil and auxiliary contacts realize remote control and status feedback, data can be uploaded to SCADA or power monitoring system via communication bus.

Onboard componentsCurrent transformer group, Micrologic electronic trip unit, main contact assembly, air arc extinguishing chamber, spring energy storage mechanism, drawout chassis, closing coil, shunt trip coil, auxiliary contact set and metal insulated housing.

LED indicatorsFront LEDs indicate power, ready, fault trip and communication status; mechanical indicators display ON, OFF and trip position.

Hardware self‑diagnosisTrip unit continuously monitors CT signal, internal power supply and communication link. Protection parameters and alarm thresholds can be adjusted locally or remotely.

Programming softwareEcoStruxure Power Commission, used for protection curve configuration, parameter backup and fault record query.

Electrical & Process Parameters

Model: NW4100T33WP22 Brand: Schneider Electric Device type: Air circuit breaker Frame rating: 4000 A Pole: 3P Mount type: Draw-out Trip unit: Micrologic LSI/LSIG Function: Overload, short-circuit protection, remote control and status supervision for main low voltage distribution circuits

Mechanical & Structure

Mounting: Draw-out rack mounting inside low voltage switchgear Protection class: IP30 (front), IP20 for rear terminal compartment Housing: Metal composite enclosure with arc chute assembly

Environmental

Operating temperature: -25℃ ~ +60℃ Storage temperature: -40℃ ~ +85℃ Ambient humidity: 5~95% non‑condensing

Certification: CE, IEC60947-2, UL Status: Original Schneider electrical distribution spare

Installation

Cut off upstream power supply before replacement. Insert breaker into drawout chassis, lock test/connected position, tighten main bus connection bolts, wire closing coil, shunt trip, auxiliary and communication cables, configure protection parameters, test energy storage, close, open and remote trip function after commissioning.

Interface

Three-phase main bus terminals, energy storage / closing coil terminals, shunt trip terminals, auxiliary/status contact terminals, communication bus terminals.

Diagnostic

Overload trip: Continuous load current exceeds long delay setting. Short-circuit trip: Severe short circuit on downstream circuit. Remote close failure: Energy storage incomplete or coil supply abnormal.

Product Brief

NW4100T33WP22 circuit breaker, Schneider Masterpact NW 3P 4000A draw-out ACB spare for large industrial main incoming low voltage power protection replacement.
