SUCO 0660S2S2 Pressure Transmitter

Feature & Principle

It is a piezoresistive pressure transmitter manufactured by SUCO. The sensing chip is placed inside an oil-filled sealed cavity to isolate the sensing element from the measured medium. Pressure deforms the diaphragm and transmits pressure to the piezoresistive chip, then the circuit converts resistance variation into standard 4-20mA signal. It has built-in reverse polarity protection, strong vibration and shock resistance, and optional FKM/NBR seals for different media. It can be used for vacuum, low pressure and general industrial pressure monitoring.

Specifications

Model: 0660S2S2 Brand: SUCO Series: 0660 Sensing principle: Piezoresistive, oil-filled cell Supply voltage: 10 ~ 32 VDC Output: 4-20mA Housing material: 1.4305 stainless steel Thread: G1/4 Accuracy: ±0.5% FS Response time: ＜2ms Application: Hydraulic station, compressed air system, hydrogen equipment, general industrial pressure monitoring Certification: CE

Components & Diagnostics

Pressure sensing chip, oil-filled isolation diaphragm, signal conditioning PCB, stainless steel housing, connector assembly. Common faults: zero drift, diaphragm damage and medium leakage, no signal output, short circuit caused by water ingress.

Product Brief

0660S2S2 pressure transmitter, SUCO industrial pressure measuring spare widely used for hydraulic and pneumatic equipment overhaul and replacement.
