Allen-Bradley 1336T-GT1-SP34B 1336 FORCE AC Drive Unit

Module Feature

1336T-GT1-SP34B belongs to 1336 FORCE high-performance AC drive manufactured by Allen-Bradley (Rockwell Automation), B frame construction. It supports V/F,open-loop and closed-loop vector control for induction motors. Equipped with multi-channel digital and analog I/O terminals,expansion slot for communication adapters such as Data Highway Plus. Integrated dynamic braking transistor,LED status display and keypad interface. Widely used in fans,water pumps,conveyors,packaging lines and heavy-duty process automation equipment.

Working principle

Three-phase AC mains power is rectified to DC bus. IGBT power stage outputs adjustable voltage and frequency AC to regulate induction motor speed and torque. Accepts analog,digital or network command signals. Closed-loop vector mode enables high starting torque and accurate speed regulation. Dynamic braking circuit consumes regenerative energy during motor deceleration.

Onboard components

Input rectifier bridge,IGBT power module,main control PCB,LED keypad panel,dynamic braking transistor,temperature controlled cooling fan,power terminal block,control I/O terminal block,communication adapter expansion slot.

LED indicators

Power LED,run status LED,fault alarm LED.

Hardware self-diagnosis

Overvoltage,undervoltage,overcurrent,overtemperature,output short circuit,earth fault,phase loss,motor overload,expansion card communication fault detection.

Programming software

DriveExplorer software,supports motor auto-tune,real-time speed monitoring,fault log reading and parameter backup & restore.

Electrical & Process Parameters

Model:1336T-GT1-SP34B Brand:Allen-Bradley Device type:1336 FORCE AC Adjustable Frequency Drive Input voltage:380 ~ 480VAC three phase Input frequency:50/60Hz Control mode:V/F,open-loop vector,closed-loop vector Communication:Expandable via optional communication adapter card Cooling:Forced air cooling Protection:Over temperature,over current,over voltage,under voltage,short circuit,earth fault,phase loss,motor overload protection

Mechanical & Structure

Mounting:Panel mounting inside control cabinet Protection class:IP20 Housing:Metal frame housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:20~80% non-condensing Certification:CE,UL compliant Status: Allen-Bradley 1336 FORCE heavy-duty variable frequency drive for industrial process and material handling applications

Installation

Follow ESD safety procedure before handling.Mount vertically and reserve sufficient ventilation gap.Separate power cables and signal cables to reduce EMI interference.Connect three-phase mains to L1/L2/L3 terminals and motor cable to U/V/W terminals.Complete motor auto-tune and parameter commissioning before operation.

Interface

Main power terminal,motor output terminal,digital/analog I/O terminal,communication adapter slot,keypad port.

Diagnostic

Over current:motor winding short circuit,cable damage or mechanical jam. Overheat:blocked heat sink or continuous overload. Under voltage:input mains fluctuation or phase missing. Unstable motor speed:incorrect motor parameters or poor shielding of signal wires. Communication fault:expansion adapter poor contact or wiring error.

Product Brief

Allen-Bradley 1336T-GT1-SP34B 1336 FORCE AC variable frequency drive,380-480V three phase input,supports V/F and vector motor control,with dynamic braking and communication expansion slot,for process pump,fan and conveyor industrial automation.
