AMAT 0100‑91146 IHC Chassis Main Backplane PCB Assembly

Technical Specifications

Model：0100‑91146（Matching part number:0120‑93488）

Brand：AMAT Applied Materials

Product Type：IHC chassis main backplane PCB assembly

Applicable System：AMAT Centura series 200mm semiconductor process equipment,IHC internal chassis unit

Supply Voltage：System backplane power distribution 5V,±12V

Interface：Multiple internal slot connectors for sub‑board signal interconnection

Common Revision：Multiple hardware revisions available

Status Indicator：No on‑board LED,status displayed by plug‑in daughter boards

Built‑in Function：Power distribution inside IHC chassis,multi‑channel internal signal routing,inter‑board signal interconnection,mechanical positioning for sub‑modules

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Fixed installation inside IHC chassis

Weight：0.33kg

Product Brief:

0100‑91146 is legacy IHC chassis main backplane PCB assembly manufactured by AMAT Applied Materials. It serves as internal power and signal interconnection base inside Centura IHC chassis. It distributes system power and routes multi‑channel control signals between each plug‑in sub‑board. Multiple slot connectors provide stable mechanical positioning and reliable signal transmission for daughter modules. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and chassis compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
