AMAT 0120‑93488 IHC Chassis MBoard PWBA

Technical Specifications

Model：0120‑93488（Bare PCB reference:0100‑91146）

Brand：AMAT Applied Materials

Product Type：IHC chassis main backplane PWBA populated assembly

Applicable System：AMAT Centura series 200mm semiconductor process equipment,IHC internal chassis unit

Supply Voltage：System backplane power distribution 5V,±12V

Interface：Multiple slot connectors for daughter‑board power and signal interconnection

Common Revision：Multiple hardware revisions available

Status Indicator：No on‑board LED,working status displayed by plug‑in daughter boards

Built‑in Function：IHC chassis internal power distribution,multi‑channel control signal routing,inter‑board signal interconnection,mechanical positioning for plug‑in sub‑modules

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Fixed installation inside IHC chassis

Weight：0.33kg

Product Brief:

0120‑93488 is legacy populated IHC chassis main backplane PWBA manufactured by AMAT Applied Materials,component‑populated assembly corresponding to bare PCB 0100‑91146. It serves as power and signal interconnection mother‑board inside Centura IHC chassis. It distributes system power supply and routes multi‑channel control signals among each plug‑in daughter board. Multiple slot connectors provide stable mechanical positioning and reliable signal transmission for sub‑modules. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and chassis compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
