AMAT 0130‑14003 Leak Detect Schematic PCB

Technical Specifications

Model：0130‑14003

Brand：AMAT Applied Materials

Product Type：Bare leak detect schematic PCB

Applicable System：AMAT Centura 200mm semiconductor process equipment

Supply Voltage：5V,±12V auxiliary power supply

Interface：Pad layout for leak sensor and system signal connectors

Common Revision：Multiple hardware revisions available

Status Indicator：No onboard LED, component‑mount bare circuit substrate

Built‑in Function：Circuit substrate for leak‑detect signal acquisition,signal conditioning circuit layout,alarm signal trace routing,mechanical mounting positioning

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Chassis internal fixed installation

Weight：0.22kg

Product Brief:

0130‑14003 is legacy bare schematic PCB manufactured by AMAT Applied Materials. It serves as unpopulated bare circuit substrate for leak‑detect interface board assembly,matched with component assembly 0100‑14003. It provides complete circuit trace layout for leak sensor signal acquisition,signal conditioning and alarm output function. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and equipment compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
