AMAT 0100‑14003 Leak Detect Interface PCB Assembly

Technical Specifications

Model：0100‑14003

Brand：AMAT Applied Materials

Product Type：Leak detect interface PCB assembly

Applicable System：AMAT Centura 200mm semiconductor process equipment

Supply Voltage：5V,±12V auxiliary power supply

Interface：Multi‑pin signal connectors for leak sensor and system interconnection

Common Revision：Multiple hardware revisions available

Status Indicator：On‑board LED for leak alarm and board operating status

Built‑in Function：Leak sensor signal acquisition,leak alarm signal output,signal conditioning,fault monitoring,data communication with main control unit

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Chassis internal fixed installation

Weight：0.42kg

Product Brief:

0100‑14003 is legacy leak detect interface PCB assembly manufactured by AMAT Applied Materials. It serves as signal acquisition and processing interface for equipment leak monitoring sensors on Centura wafer processing platform. It collects sensing signals from leak detectors,performs signal conditioning and outputs alarm trigger signals to host control system. On‑board LED provides direct visual indication for leakage alarm and board operating status. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and equipment compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
