B&R 2AO300.6 Analog Output Module

Technical Specifications

Model:2AO300.6

Brand:B&R

Product Type:Analog Output Module

Applicable System:B&R System2010 PCC control system, packaging, textile, printing and plastic machinery

Matching base plate:BP200, BP201, BP210

Channel quantity:16 voltage output channels

Output range:‑10V ~ +10V bipolar voltage

Resolution:12‑bit

Conversion time:250μs for all channels

Filter:1‑order low‑pass filter, cutoff frequency 1000Hz

Isolation:Isolation between output side and PCC controller, no isolation among channels

Weight:0.70kg

Installation:Insert into System2010 backplane base plate

Working temperature:0℃ ~ +60℃

Storage temperature:‑40℃ ~ +85℃

Protection class:IP20

Built‑in function:Digital‑to‑analog conversion, multi‑channel analog voltage signal output, signal filtering processing, surge suppression, provides analog control signals for frequency converters, proportional valves and field analog actuators

Product Brief

2AO300.6 is B&R System2010 series 16‑channel analog output module, dedicated for multi‑point analog voltage control in old‑generation PCC systems.

It converts controller digital values into stable ±10V analog voltage signals, with 12‑bit resolution and total‑channel 250μs fast conversion speed, equipped with built‑in low‑pass filter to restrain high‑frequency noise interference. The module supports output‑to‑controller isolation, effectively reduces ground loop interference from field site.

This module must be used together with BP200 / BP201 / BP210 base plate, widely used for packaging, textile and plastic machinery analog regulating control loops.

This is EOL discontinued spare part, mainly used for maintenance and renovation of existing System2010 automation equipment. Please confirm base‑plate model and system hardware compatibility before purchase. Strict ESD anti‑static protection shall be followed during installation.
