B&R 2BM100.9 System2010 Dummy Module

Technical Specifications

Model:2BM100.9

Brand:B&R

Product Type:Dummy Filler Blank Module

Applicable System:B&R System2010 PCC rack, matches BP200,BP201,BP210 base plate backplane

Function:Fill vacant slot position on System2010 backplane rack

Installation:Plug‑in insert into empty I/O slot of System2010 base plate

Degree of protection:IP20

Weight:0.12kg

Working temperature:‑25℃ ~ +60℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function:Covers unused rack slots, guarantees cabinet internal air convection channel, maintains rack electromagnetic shielding performance, prevents dust and foreign matter entering backplane slot

Product Brief

2BM100.9 is B&R System2010 series dummy filler blank module, specially used for filling unused slots on System2010 backplane base plate.

When some slots of System2010 rack are not equipped with functional I/O modules, install 2BM100.9 dummy module to block vacant openings. It can keep original cabinet air‑flow path, avoid cooling air short‑circuit, and ensure normal heat dissipation of adjacent working modules. Meanwhile it maintains rack electromagnetic shielding effect, prevents dust and metal debris from falling into backplane connector and avoids short‑circuit risk.

This dummy module is purely mechanical filler without circuit and communication function, plug‑and‑play without software configuration, widely used for cabinet reconstruction and spare‑slot processing of old‑generation System2010 automation equipment.

This is EOL discontinued spare part. Please confirm System2010 base‑plate model before purchase. Follow ESD protection rules during installation.
