B&R 2CP100.60‑1 System2010 CPU Module

Technical Specifications

Model:2CP100.60‑1

Brand:B&R

Product Type:System2010 CPU Central Processing Unit

Applicable System:B&R System2010 PCC control system, packaging, textile, printing and plastic machinery

Matching base plate:BP200, BP201, BP210

Memory:256KB SRAM,128KB dual‑port RAM

Local bus:X2X‑Link I/O expansion bus

Serial interfaces:1×RS232,1×isolated RS232/TTY,1×isolated RS485/RS422

Programming software:Automation Studio, supports IEC61131‑3 standard languages

Installation:Plug‑in on System2010 backplane base plate

Weight:1.40kg

Degree of protection:IP20

Status indicator:Multi‑segment LED status display for run, fault and communication diagnosis

Working temperature:0℃ ~ +60℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function:Real‑time multi‑task program processing, X2X‑Link distributed I/O management, multi‑serial protocol communication, loop fault diagnosis, complete logic control for old‑generation mechanical equipment

Product Brief

2CP100.60‑1 is B&R System2010 series standard CPU module, serves as core control unit for System2010 PCC system, must be used with BP200 / BP201 / BP210 base plate backplane.

It is equipped with 256KB SRAM working memory and 128KB dual‑port RAM data buffer, integrates multiple serial communication interfaces, RS232/TTY and RS485/RS422 channels adopt electrical isolation design to improve anti‑interference performance on industrial site. X2X‑Link local bus realizes high‑speed data exchange with peripheral I/O modules.

Program development relies on Automation Studio, supports IEC61131‑3 standard programming languages, widely used for packaging, textile and plastic forming equipment transformation and maintenance. Front‑panel multi‑state LED indicators facilitate technicians to judge CPU running status and communication fault quickly.

This is EOL discontinued spare part, mainly used for maintenance and renovation of existing System2010 automation equipment. Please confirm base‑plate model and hardware version before purchase. Strict ESD anti‑static protection shall be followed during installation.
