B&R 4D1044.00‑090 Panelware Display Module

Technical Specifications

Model:4D1044.00‑090

Brand:B&R

Product Type:Panelware Display Module With Keypad

Applicable System:B&R Panelware HMI system, cooperate with 4C series panel controller for System2005 automation equipment

Display:4 lines × 40 characters monochrome LCD, LED backlight, black‑on‑yellow, character height 4.3 mm

Keypad:Integrated matrix function keypad, supports custom key label insertion

Dimension:288mm96mm35mm

Weight:1.00kg

Installation:Cabinet front‑panel cut‑out mounting

Degree of protection:Front IP54, rear IP20

Certification:CE, cULus, Class I Div.2 hazardous location approval

Working temperature:0℃ ~ +50℃

Storage temperature:‑20℃ ~ +60℃

Relative humidity:10‑90% non‑condensing

Built‑in function:Character‑based process value and alarm text display, keypad input capture, receives display commands from Panelware backend controller, no independent control logic

Product Brief

4D1044.00‑090 is B&R EOL discontinued Panelware display‑keypad unit. It contains LCD screen and matrix keypad, and must be matched with 4C‑series Panelware backend controller, cannot work standalone.

Adopting 4×40 character black‑on‑yellow LCD with LED backlight, it can display abundant process texts, production set‑points and fault alarm messages. Integrated matrix keypad realizes parameter modification and machine operation.

Cabinet front‑panel mounting structure with front‑side IP54 rating provides dust and splash resistance for cabinet environment. Wide environmental humidity tolerance adapts to various industrial cabinet conditions.

This is legacy EOL spare part for old‑generation packaging, textile and plastic machinery maintenance. Please confirm matching Panelware backend controller and panel cut‑out dimension before purchase. Strict ESD anti‑static protection shall be followed during installation.
