B&R 4P3040.01‑490 PP41 Power Panel

Technical Specifications

Model:4P3040.01‑490

Brand:B&R

Product Type:PP41 Power Panel Integrated HMI‑PLC Controller

Applicable System:B&R System2003 automation platform, packaging, textile and food‑processing machinery

Display:5.7‑inch QVGA monochrome LCD,320×240 pixels,LED backlight,150 cd/m² typical brightness,50000h half‑brightness lifespan

Key array:8 soft keys,32 function keys with status feedback, supports custom key‑label insertion

Memory:700KB SRAM,1.4MB FlashPROM non‑volatile program memory, lithium‑battery‑backed real‑time clock

Expansion resource:1×PCMCIA slot,6 internal screw‑in adapter‑module slots for function expansion

On‑board I/O:10×24VDC digital inputs,8×24VDC digital outputs,0.4A per output channel, TB712 terminal blocks must be ordered separately

Communication interfaces:1×RS232 DSUB‑9 connector,1×galvanic isolated CAN‑bus DSUB‑9 connector, max 500k‑bps baud rate

Power supply:18‑30VDC DC input

Installation:Cabinet front‑panel cut‑out mounting

Dimension:205mm220mm110.4mm

Weight:2.00kg

Degree of protection:Front‑side IP65, rear‑side IP20

Certification:CE, cULus industrial control certification

Working temperature:0℃ ~ +50℃

Storage temperature:‑20℃ ~ +60℃

Relative humidity:10‑90% non‑condensing

Built‑in function:Independent local PLC program execution, graphic process‑data visualization, equipment set‑point modification, alarm‑message output, onboard digital signal acquisition and output control, cyclic CAN‑bus field‑bus data exchange, PCMCIA‑card supported project backup and data logging, flexible function expansion via internal adapter modules.

Product Brief

4P3040.01‑490 is B&R EOL discontinued PP41 series all‑in‑one Power Panel for System2003 automation platform. This unit combines PLC controller and graphic HMI terminal into single cabinet‑mount hardware, capable of running complete machine automation logic without external host CPU unit.

5.7‑inch QVGA monochrome graphic LCD presents equipment process values and alarm information clearly. Combined soft‑key and function‑key array realizes convenient local operation. On‑board digital I/O directly connects field sensors and actuators. Galvanic isolated CAN‑bus port effectively suppresses industrial ground‑loop interference and guarantees stable field‑bus communication performance.

PCMCIA slot provides convenient project backup and process‑data logging function. Six internal screw‑in adapter‑module slots support flexible hardware function expansion. Front‑side IP65 protection rating adapts to standard industrial cabinet‑mount environment.

This is legacy EOL spare part for old‑generation packaging, textile and food‑processing equipment maintenance and renovation. Please confirm System2003 project compatibility, TB712 terminal‑block availability and panel cut‑out dimension before purchase. Strict ESD anti‑static protection shall be followed during installation.
