B&R 5PP120.1043‑K04 Power Panel PP120

Technical Specifications

Model:5PP120.1043‑K04

Brand:B&R

Product Type:PP120 series integrated cabinet‑mount Power Panel HMI unit

Applicable System:B&R GPOS runtime system,packaging machinery,bottle filling production line,textile equipment and general industrial automation projects

Display:10.4‑inch color TFT‑LCD,VGA 640×480 resolution,CCFL backlight

Touch type:Analog resistive touch screen,support glove operation for dusty and oily workshop environment

Memory:128 MB onboard SDRAM

Storage interface:1×CompactFlash Type‑I slot for system boot,HMI project and recipe data storage

Communication interfaces:1×10/100Mbps Ethernet,1×RS232 DSUB‑9 serial port,2×USB1.1 Type‑A host port

Real‑time clock:Built‑in replaceable lithium backup battery for RTC time and configuration parameter retention

Power supply:24VDC ±25% SELV input;power terminal block 0TB103.9 / 0TB103.91 ordered separately;typical power consumption 15W,max 20W

Installation:Control cabinet front cut‑out mounting,equipped with front‑face sealing gasket

Dimension:323mm260mm65.5mm

Weight:3.70kg

Degree of protection:Front‑side IP65(NEMA4X indoor),rear‑side IP20(valid under intact gasket and standard installation)

Certification:CE,cULus certification

Working temperature:0℃ ~ +50℃

Storage temperature:‑20℃ ~ +70℃

Relative humidity:5‑95% non‑condensing,pollution degree 2

Built‑in function:All‑in‑one HMI hardware integrates display,touch and control platform. Real‑time production data display,alarm message output,recipe parameter modification and local project storage via CF card. Multi‑communication interfaces realize data exchange with field automation controllers.

Product Brief

5PP120.1043‑K04 is B&R PP120 series integrated Power Panel HMI, specially matched for special machine manufacturer configuration variant. Aluminum anodized front panel with sealing gasket realizes front‑panel IP65 protection,adapt to harsh cabinet‑installation workshop environment.

10.4‑inch VGA TFT display cooperates with analog resistive touch panel,still workable with oil stain and dust on surface. Onboard 128MB SDRAM and CompactFlash Type‑I slot support storing system runtime,HMI visualization project and mass production recipe data. Ethernet,RS232 and dual USB ports satisfy connection demand for controller and peripheral devices. Built‑in lithium battery keeps real‑time clock and configuration data after power‑off.

This belongs to legacy EOL discontinued spare part,mostly used for old‑generation production line maintenance and hardware replacement. Before purchase,please confirm GPOS system version and cabinet cut‑out dimension compatibility. ESD anti‑static measures must be taken during installation,powered‑on hot‑plug for CF card is forbidden. Front IP65 protection relies on intact sealing gasket and standard installation.
