B&R 7AI261.7 Analog Input Module

Technical Specifications

Model:7AI261.7

Brand:B&R

Product Type:Series2003 screw‑in analog input module for strain‑gauge / load‑cell measurement

Applicable System:B&R Automation Studio,Series2003 CPU system,packaging machinery,material handling,weighing and force‑monitoring applications

Signal Input:1 channel full‑bridge strain‑gauge / load‑cell,4‑wire connection,input range 1‑16 mV/V

Converter Resolution:24‑bit high‑precision ADC

Update Rate:6 Hz fixed measurement cycle

Excitation Output:5 V sensor excitation for bridge transducer

Isolation:Galvanic isolation between field side and controller backplane

Power supply:24VDC SELV input,power supplied via Series2003 backplane

Installation:Screw‑in plug‑in module for Series2003 base holder

Dimension:120mm34mm23mm

Weight:0.13kg

Degree of protection:IP20(module interior)

Certification:CE,cULus,UKCA certification

Working temperature:‑20℃ ~ +60℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5‑95% non‑condensing,pollution degree 2

Built‑in function:High‑precision acquisition for full‑bridge strain‑gauge and load‑cell sensors. Provides stable 5V bridge excitation,converts tiny mV/V mechanical‑deformation signals into digital values for controller processing. Realize weight calculation,force monitoring and material‑stress measurement in automation systems.

Product Brief

7AI261.7 is B&R Series2003 screw‑in analog input module specially designed for strain‑gauge and load‑cell transducers. It supplies 5V excitation for 4‑wire full‑bridge sensors and captures weak 1‑16 mV/V measurement signals with 24‑bit high‑resolution conversion. Fixed 6 Hz update rate fits static and quasi‑static weighing and force‑monitoring tasks.

Module adopts screw‑in plug‑in structure,quickly mounts onto Series2003 backplane base unit. Galvanic isolation improves anti‑interference performance for industrial field environment. It is widely deployed in packaging,logistics and machinery equipment for weight detection and pressure‑force monitoring.

This is legacy EOL discontinued spare part,mainly used for old‑generation Series2003 automation system maintenance and hardware replacement. Before purchase,please confirm Series2003 backplane compatibility and sensor bridge parameter matching. ESD anti‑static protection shall be performed during installation. Do not plug/unplug module under powered‑on state.
