B&R X20DS1119 Multifunction Digital Signal Processor Module

Technical Specifications

Model:X20DS1119

Brand:B&R

5V channel:3‑channel symmetrical,configurable input / output

24VDC input:2‑channel digital sink input

Counter function:Universal counter pair,AB counter,up/down counter,2 event counters

Motion generator:A/B direction/frequency output,1 reference pulse

Encoder interface:SSI absolute encoder support

Timestamp:NetTime microsecond edge‑capture timestamp

Power consumption:0.01W(bus logic),1.5W(I/O circuit)

Protection class:IP20

Horizontal operating temperature:‑25℃ ~ +60℃

Vertical operating temperature:‑25℃ ~ +50℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function

X20DS1119 multifunction digital signal processor handles complex motion‑related signal acquisition and generation for X20 control system. 3‑channel 5V symmetrical ports can be switched between input and output mode. It supports counter acquisition,SSI absolute encoder reading and encoder emulation for master‑following applications. Microsecond‑level NetTime timestamp realizes precise edge capture independent of PLC bus cycle,support local X20 I/O and distributed X2X‑Link remote stations。

Product Brief

X20DS1119 belongs to B&R X20 I/O system family,coated variant X20cDS1119 is available for harsh environment. Bus module and terminal block need to be ordered separately. Shielded cables are required for 5V signal wiring. Widely used for original B&R automation equipment maintenance and renovation. Before purchase,please confirm signal type and motion function requirement. ESD anti‑static protection shall be followed during installation
